Xantrex Freedom XC Pro Inverter Charger (MPN: 818-3010)

High-performance inverter and battery charger for 12 volt systems.

The Xantrex Freedom XC Pro is a versatile inverter and battery charger designed for 12 volt battery systems. It delivers a continuous output of 3000 watts and can handle surges up to 6000 watts, making it suitable for powering sensitive electronics and motor loads. With a true sine wave output, it ensures compatibility with a wide range of devices, including refrigerators and microwaves, while maintaining efficiency with a 91 percent rating.

This unit operates effectively in a wide temperature range from 4 to 140 degrees Fahrenheit, allowing for reliable performance in various environments. The inverter features programmable AC under-voltage shutdown, which is particularly useful for maintaining operation under weak shore power or generator input. Additionally, the built-in 30 ampere AC transfer relay automatically switches the load from the inverter to an external power source when available, enhancing convenience and functionality.

Installation is simplified with quick connect terminals for AC input and output, and an easy access wiring compartment for both AC and DC connections. The onboard display provides real-time information on AC and battery current, ensuring users can monitor performance effectively. The Freedom XC Pro is ETL listed to multiple standards, ensuring safety and reliability in its operation.

Features

• Extended Surge Rating: Surges To 2X Continuous Power For 2 Seconds For Motor Loads
• True Sine Wave AC Power For Operation Of Sensitive And Motor Loads
• Ignition Control To Turn Inverter On Or Off Via A 12 Volt DC Signal And To Minimize Battery Drain By Switching The Inverter Off When The Ignition Key Is Turned Off
• Wide 10 To 18 Volt DC Input Rang Ensures Inverter Operation On High Voltage Alternators Found On Many New Vehicle Chassis
• Programmable AC Under-Voltage (85 To 110 Volt AC) Shutdown Is Ideal To Operate Under Weak Shore Power Or Generator Input
• Built-In 30 Ampere AC Transfer Relay Senses When Outside AC Power Is Present And Transfers The Load From The Inverter To The Source Of Incoming Power
• View AC And Battery Current, Percent Status Bar For Inverter Output On The Onboard Display
• Hardwire Or Plug Directly Into The Optional 20 Ampere GFCI Receptacle
• Easy Access AC And DC Wiring Compartment For Quick Installation

Specifications

• Manufacturer: Xantrex
• Manufacturer Part Number: 818-3010
• Compatibility: 12 Volt Batteries
• Smart Technology Compatible: Not Compatible With Smart Technology
• Continuous Power Output: 3000 Watt
• Input Voltage: Inverter: 10.5 To 15.5 Volt DC/ Charger: 90 To 130 Volt AC
• Peak Power Output: 6000 Watt
• Ampere Rating: 150 Amp
• Efficiency: 91 Percent
• Operating Temperature: 4 To 140 Degree Fahrenheit
• Standards: ETL listed To CSA 107.1/ UL458/ ABYC E11/ A-31/ A-32

Technical Documents

• Freedom_X_GFCI_Device_Installation_Guide_(975-0788-01-01_Rev-A)_ENG.pdf
• 975-0799-01-01_Rev-D(Freedom_XC_PRO_Owners_Guide)_ENG.pdf
• 976-0367-01-01_Rev-E(Freedom_X_Remote_Panel_User_Guide)_ENG.pdf
• Freedom_XC_Warranty_Terms_n_Conditions_NA.pdf
• 20200415_FREEDOMXCPRO_Datasheet.pdf
• FXC_PRO_Remote_compatibility_Memo.pdf
• Freedom_X_GFCI_Device_Installation_Guide_(975-0788-01-01_Rev-A)_ENG.pdf
• 20210218_FREEDOMXCPRO_UserGuide.pdf
