Turbo Smart Comp-Gate40 Wastegate (MPN: TS-0505-1006)

Advanced wastegate design for enhanced turbo performance and reliability.

The Turbo Smart Comp-Gate40 Wastegate is engineered for optimal performance in turbocharged applications. This 40 mm wastegate features a robust one-piece coated stainless steel valve and a silicon Nomex diaphragm, ensuring reliability and performance under demanding conditions. The unique collar-locking system allows for reduced size and quicker spring changes, making it a practical choice for tuners and enthusiasts alike.

Designed with a mechanical control type, the Comp-Gate40 offers an adjustable PSI range of 7 pounds per square inch, providing flexibility for various setups. The V-band inlet and outlet connections facilitate easy installation and compatibility with 40 millimeter peer fitment. Additionally, the wastegate is equipped with twin and 1/16 NPT reference ports, enhancing its versatility in different configurations.

This wastegate is smaller and lighter than previous models, contributing to improved overall system efficiency. With optional liquid-cooling capabilities and a range of spring options from 3 to 26 psi, the Turbo Smart Comp-Gate40 is a direct fit upgrade for all 4th-generation Turbosmart wastegates, making it a valuable component for performance tuning.

Features

• Solid One-Piece Coated Stainless Steel Valve
• Silicon Nomex Diaphragm Proven For Performance And Reliability
• Unique Locking Collar Design For Reduced Size And Quicker Spring Changes
• V-Band Inlet And Outlet To Suit 40 Millimeter Peer Fitment
• Designed With Minimum Size And Flow
• Smaller And Lighter Than The Previous Model
• Twin And 1/16 NPT Reference Ports

Specifications

• Manufacturer: Turbo Smart
• Manufacturer Part Number: TS-0505-1006
• Control: Mechanical
• Type: External
• Diameter: 1.57 Inch
• PSI Range: 7 Pounds Per Square Inch
• Adjustable: Yes
• Wastegate Base Material: Stainless Steel

Technical Documents

• Collar_and_IWG_Spring_Chart.pdf
