Triple-R Light Linear-6 Elite LED Light Bar (MPN: LNR-PLUS-6)

Advanced LED technology for superior visibility in all conditions.

The Triple-R Light Linear-6 Elite LED Light Bar represents a significant advancement in LED lighting solutions, designed for optimal performance and versatility. This light bar features a combination of 12 high-output white LEDs and 6 yellow LEDs, providing exceptional illumination with a maximum output of 7,100 lumens in Combo mode. The unique design allows for multiple lighting modes, including Boost, Combo, Snow/Fog/Dust Mode, and Low output, ensuring adaptability to various environmental conditions.

The Linear-6 Elite is engineered with a low-profile design that facilitates easy installation while maintaining a sleek appearance. The polycarbonate lens is hard-coated for durability and is rated IP68 for watertight protection, making it suitable for harsh weather conditions. The momentary switch allows for seamless transitions between lighting modes, and the memory function recalls the last used setting, enhancing user convenience.

With a power consumption of 69 watts and a current draw of 5.1 amps at 14 volts, this light bar is efficient without compromising on brightness. The combination of white and yellow LEDs is particularly effective in snow, fog, and dust, providing enhanced visibility and safety. The Linear-6 Elite is compatible with one-lamp and two-lamp wiring kits, making it a versatile choice for various applications.

Features

• Combination Of Highly Efficient White And PC-Yellow LEDs
• Yellow LEDs Optimized For Use In Snow, Fog And Dust Conditions
• Compatible One-Lamp Or Two-Lamp Wiring Kits Available
• Momentary Switch Facilitates Switching Lighting Modes
• Memory Function Recalls Preferred Lighting Mode Without Needing To Re-Select Each Journey
• Sleek, Low Profile Design Facilitates Installation
• ‘Unbreakable’ And Hard Coated Polycarbonate Lens
• IP68 Watertight

Specifications

• Manufacturer: Triple-R Light
• Manufacturer Part Number: LNR-PLUS-6
• Bulb Type: LED
• Style: Straight
• Length: 9-1/8 Inch
• Number Of Rows: 1
• Light Color: Amber/ White
• Housing Color: Black
• Beam Angle (Deg): 84 Degree
• Lumens: 5100 Lumens White Beam/ 2000 Lumens Yellow Beam/ 7100 Lumens White And Yellow Beam
• Wattage: 48 Watt White Light/ 21 Watt Yellow Light/ 5.1 Watt White And Yellow Light
• Width: 2.4 Inch
• Height: 1.57 Inch
• Voltage Rating: 10 To 32 Volt
• Ampere Rating At 12 Volts: 3.6 Amp White Light/ 1.5 Amp Yellow Light/ 6.9 Amp White And Yellow Light
• Bulb Specifications: 12 White/ 6 Yellow High Output 3 Watt LED Bulbs
• Lens Material: Polycarbonate
• Mounting Length: 10.24 Inch
• Mounting Style: Side Mount
• Includes: With Anti-Theft Side Mount Kit
• Marine: No

Technical Documents

• linear-6_elite_-_instructions_-_triple-r_lights.pdf
• linear-6-elite_-_product_information_card_-_triple-r_lights.pdf
