T-H Marine Outboard Motor Jack Plate (MPN: 13003)

Enhance boat performance in shallow waters with innovative design.

The T-H Marine BA-130 Breakaway unit is engineered for boaters navigating shallow and stumpy waters, providing a practical solution for duck hunters and fishermen. This jack plate is mounted between the boat transom and the outboard motor, accommodating motors up to 130 horsepower. It allows small boats to glide over submerged logs and debris at low speeds, minimizing potential damage to both the outboard motor and the boat transom.

When encountering an obstruction at speeds under 5 miles per hour, the BA-130's design enables the motor to deflect and rotate up to 45 degrees, allowing for safe passage over obstacles. A built-in drawbar spring ensures that the motor returns to its standard running position after the obstruction is cleared, while also maintaining the motor's position during reverse operation at low RPM. The unit features a standard B.I.A. hole pattern for easy installation, making it compatible with various outboard motors.

Constructed from polished aluminum, the BA-130 is lightweight at 28 pounds and designed for durability. It is important to note that this unit is not intended for use when reversing over obstructions. The manual adjustment type and 6-inch setback further enhance its functionality, making it a reliable choice for those who frequently operate in challenging water conditions.

Features

• Glide Safely Over Submerged Logs Or Debris At Low Speeds
• Offers 45 Degree Of Movement
• Spring Returns Motor To Standard Running Position
• Standard B. I. A. Hole Pattern

Specifications

• Manufacturer: T-H Marine
• Manufacturer Part Number: 13003
• Adjustment Type: Manual
• Setback: 6 Inch
• Maximum Horsepower: 130 Horsepower
• Finish: Polished
• Color: Silver
• Material: Aluminum
• With Rocker Switch: No
• With Relay Harness: No
