SpeedFX In-Line Fuel Filter (MPN: 5779081CLR)

High-performance fuel filter designed for street and racing applications.

The SpeedFX In-Line Fuel Filter is engineered from high-quality 6061 aluminum, ensuring both strength and durability for demanding automotive environments. This filter features a slim design with a 1-1/4 inch outer diameter, facilitating easy installation in various setups. It is specifically designed for alcohol fuel types and includes a cleanable 40 Micron wire mesh element, which can be accessed quickly due to its FKM O-ring sealed single end cap design.

With a flow rate of 95 gallons per hour at 7 PSI, this filter is suitable for both race and street applications, providing reliable performance under pressure. The replaceable disc style filter allows for bi-directional filtering, enhancing its versatility. Manufactured in the U.S.A., the SpeedFX In-Line Fuel Filter combines functionality with quality craftsmanship, making it a valuable component for any fuel system.

Features

• Manufactured With 6061 Billet Aluminum For Strength And Durability
• Slim 1-1/4 Inch O.D. Allows For Easy Mounting
• Flow Rate Of 95 Gallons Per Hour At 7 PSI For Race Or Street Applications
• 40 Micron Element Is Easy To Access And Can Be Cleaned Or Replaced
• Replaceable Disc Style Filter Allows For Bi-Directional Filtering
• Made In U.S.A

Specifications

• Manufacturer: SpeedFX
• Manufacturer Part Number: 5779081CLR
• Type: Element
• Location: In-Line
• Fuel Type: Alcohol
• Inlet Connection Size: -8 AN
• Inlet Connection Type: Male Threads
• Outlet Connection Size: -8 AN
• Outlet Connection Type: Male Threads
• Diameter (IN): 1-1/4 Inch
• Length (IN): 4 Inch
• Width (IN): 1-1/4 Inch
• Height (IN): 1-1/4 Inch
• Micron Rating: 40 Micron
• Element Material: Screen
• Finish: Anodized
• Color: Clear
• Material: Aluminum
• With Gasket: No
• With Hose: No
• With Mounting Hardware: No
• Estimated Install Time (Hours): 0.5
