SpeedFX In-Line Fuel Filter (MPN: 5779061CLR)

High-performance fuel filter designed for demanding applications.

The SpeedFX In-Line Fuel Filter is engineered from 6061 aluminum, ensuring strength and durability for both street and racing environments. This filter features a slim design with a 1-1/4 inch outer diameter, facilitating easy installation in tight spaces. It is equipped with a 40 Micron wire mesh element that is easily accessible for cleaning or replacement, promoting long-term use and efficiency.

With a flow rate of 95 gallons per hour at 7 PSI, this filter is suitable for alcohol fuel types and supports bi-directional filtering through its replaceable disc style design. The anodized clear finish not only enhances its aesthetic appeal but also provides additional protection against corrosion. This product is proudly made in the U.S.A, reflecting high manufacturing standards and quality.

Features

• Manufactured With 6061 Billet Aluminum For Strength And Durability
• Slim 1-1/4 Inch O.D. Allows For Easy Mounting
• Flow Rate Of 95 Gallons Per Hour At 7 PSI For Race Or Street Applications
• 40 Micron Element Is Easy To Access And Can Be Cleaned Or Replaced
• Replaceable Disc Style Filter Allows For Bi-Directional Filtering
• Made In U.S.A

Specifications

• Manufacturer: SpeedFX
• Manufacturer Part Number: 5779061CLR
• Type: Element
• Location: In-Line
• Fuel Type: Alcohol
• Inlet Connection Size: -6 AN
• Inlet Connection Type: Male Threads
• Outlet Connection Size: -6 AN
• Outlet Connection Type: Male Threads
• Diameter (IN): 1-1/4 Inch
• Length (IN): 3-3/4 Inch
• Width (IN): 1-1/4 Inch
• Height (IN): 1-1/4 Inch
• Micron Rating: 40 Micron
• Element Material: Screen
• Finish: Anodized
• Color: Clear
• Material: Aluminum
• With Gasket: No
• With Hose: No
• With Mounting Hardware: No
• Estimated Install Time (Hours): 0.5
