High-performance light bar with adjustable beam and brightness control.
The Shadow-Caster Eagle Ray LED Light Bar is engineered to provide exceptional illumination for various applications. With a length of 20 inches and a width of 2.5 inches, this light bar features 24 bright white LEDs that deliver an impressive 20000 lumens output. The unique combination of focused laser-driven white light beams and a 60-degree flood beam ensures optimal visibility in challenging conditions such as fog, rain, and mist.
This light bar is designed with versatility in mind, offering adjustable beam angles from 5 to 100 degrees, which can be controlled via a push button or the Shadow-Caster NMEA 2000 Light Commander interface. The blue halo illumination around the optics indicates the power state, while blue accent light strips provide visual feedback on brightness levels. Constructed with a clear borosilicate glass lens and a durable white billet aluminum housing, the Eagle Ray is built to withstand harsh environments.
Installation is straightforward with included adjustable mounting bases, 6-foot wiring, and 10-gauge power input wires. The hard-wired connection type ensures a secure and reliable setup. This light bar operates within a voltage range of 10 to 30 volts and has a maximum current draw of 16.5 amps at 12 volts, making it suitable for marine and automotive applications.
Features
- Automotive Grade Laser-Driven 2 White Lights
- Blue Halo Illumination Around Optics Indicate Power State Laser Light
- Adjustable 5 To 100 Degree Beam Angle Control With A Switch Or MFD Interface Laser Lights
- 24 Bright White Leds Flood Light
- Blue Accent Light Strips Indicate Brightness Level And 60 Degree Beam Angle Flood Light
- Adjustable Brightness Control With A Switch Or MFD Interface Flood Light
Specifications
- Manufacturer: Shadow-Caster LED Lighting
- Manufacturer Part Number: SCM-EAGLE-RAY-WH
- Bulb Type: LED
- Style: Straight
- Length: 20 Inch
- Beam Type: Flood Beam
- Number Of Rows: 2
- Light Color: White
- Housing Color: White
- Beam Angle (Deg): 60 Degree
- Lumens: 20000 Lumens
- Wattage: 200 Watt
- Width: 5.4 Inch
- Height: 2-1/2 Inch
- Voltage Rating: 10 To 30 Volt
- Ampere Rating At 12 Volts: 16.5 Amp
- Bulb Specifications: 24 Bright White LED Bulbs
- Lens Material: Glass
- Housing Material: Aluminum
- Mounting Length: 10 Inch
- Mounting Style: Screw On Mount
- Connection Type: Hard Wired
- Includes: With Adjustable Mounting Bases/ 6 Foot Wiring/ 10 Gauge Power Input Wires/ Mounting Hardware
- Marine: Yes
Technical Documents
Product Videos
Shipping & Returns
- This product ships within the continental USA only.
- This product typically ships within 1 to 3 business days.
- Returns are accepted within 30 days for items in like-new condition. For complete details, please see our return policy.
