QA1 Coil Over Shock Absorber (MPN: 2698-5M)

High-performance shock absorber for various racing applications.

The QA1 Coil Over Shock Absorber from the 26 Series is engineered for versatility across different track conditions. This monotube shock features a zinc plated steel body that offers excellent corrosion resistance, making it suitable for modifieds, late models, superstocks, and other racing classes. With an extended height of 24.63 inches and a compressed height of 15.4 inches, it provides adjustable ride height to meet specific performance needs.

Designed with number 8 compression and number 5 rebound linear valving, this shock absorber delivers precise control over suspension dynamics. The deflective disc valving system, combined with a proprietary blend of specially engineered oil, minimizes fade and ensures consistent performance. The damping curve is optimized for effective control at low shaft speeds while preventing extreme forces at high velocities, making it adaptable for rough tracks and bumpy asphalt.

This shock can be installed in any orientation without affecting its performance characteristics. It is also racer revalveable and rebuildable, ensuring long-term reliability and repeatability. The QA1 Coil Over Shock Absorber is 100 percent dyno tested, confirming its performance and durability in demanding racing environments.

Features

• Zinc Plated Steel Monotube Body
• Features Deflective Disc Valving
• Linear, Digressive And Linear/Digressive Valving Available
• Uses A Premium Proprietary Blend Of Specially Engineered Oil To Prevent Fade
• Damping Curve Allows For Complete Control Of Suspension At Low Shaft Speeds Without Creating Extreme Forces At High Shaft Velocities
• Can Be Run In Any Orientation With No Change In Rate
• Racer Revalveable And Rebuildable Designed For Unparalleled Repeatability
• 100 Percent Dyno Tested

Specifications

• Manufacturer: QA1
• Manufacturer Part Number: 2698-5M
• Adjustable: Yes
• Upper Mounting Type: Eyelet
• Lower Mounting type: Eyelet
• Extended Height (IN): 24.63 Inch
• Compressed Height (IN): 15.4 Inch
• Quantity: Single
• Valving Type: Number 8 Compression And Number 5 Rebound Linear Valving
• Shock Type: Mono Tube
• Shock Body Color: Silver
• Shock Body Material: Steel
• Spring Height (IN): No Spring
• Spring Rate: No Spring
• Spring Style: No Spring
• Spring Finish: No Spring
• Spring Color: No Spring
• Spring Material: No Spring
• Includes Mounting Hardware: No
