Project X Series X LED Driving Fog Light (MPN: AL538804-1)

High power LED lights with advanced thermal management and customizable design.

The Project X Series X LED Driving Fog Light is engineered for superior performance, utilizing 24 Osram LED bulbs to deliver a powerful combo beam. With a total output of 15000 raw lumens and 8889 effective lumens, this 7-inch round light is designed to illuminate the path ahead effectively. The hard-coated polycarbonate lens and black pressure die-cast aluminum housing ensure durability and resistance to harsh conditions, making it suitable for various applications.

This LED light features an integrated Active Thermal Management System (ATMS) that enhances its longevity and performance. The highly polished aluminum reflector is designed with precisely scalloped parabolas, providing optimal control and efficiency in light distribution. Additionally, the built-in LED light pipe meets ECE requirements, improving daytime visibility and safety for drivers.

The Project X Series X light is fully universal and surface-mounted, making installation straightforward. It is rated IP66 and IP67 for water and dust resistance, ensuring reliable operation in diverse environments. The customizable appearance, with options for blue, red, and green inner trims, allows users to tailor the look to their preferences while maintaining functionality.

Features

• Pressure Die-Cast Aluminum Housing
• High Power Osram-LEDs Produces Pure White Light
• Highly Polished Super-Efficient Aluminum Metalized Reflector Utilizing Precisely Scalloped Parabolas For Ultimate Control And Performance
• Signature Built-In LED Light Pipe Meets ECE Requirements For Front Position Light Improving Daytime Driving Visibility And Safety
• Hard Coated Polycarbonate Lens
• Customizable Appearance
• IP66 And IP67 Rated

Specifications

• Manufacturer: Project X
• Manufacturer Part Number: AL538804-1
• Shape: Round
• Beam Type: Combo Beam Flood And Spot
• Diameter: 7 Inch
• Height/ Width: Not Applicable
• Bulb Type: LED
• Light Color: White
• Quantity: Single
• Universality: Fully Universal
• Depth: 4 Inch
• Wattage: 120 Watt
• Voltage Rating: 12 Volt
• Mounting Style: Surface Mount
• Ampere Rating At 12 Volts: 8.9 Amp
• Lumens: 15000 Raw/ 8889 Effective Lumens
• Bulb Specifications: 24 OSRAM LED Bulbs
• Lens Material: Polycarbonate
• Housing Color: Black
• Housing Material: Die-Cast Aluminum
• Includes: With Blue/ Red And Green Inner Trims/ Stainless Steel Mounting Hardware Kit/ Wiring Pigtail
• Estimated Install Time (Hours): 1.5

Technical Documents

• AL538804-1_Install_Guide.pdf
