Project X Series One LED Driving Fog Light (MPN: AL538803-1)

High-performance LED light with enhanced optics for superior visibility.

The Project X Series One LED Driving Fog Light is engineered to deliver exceptional illumination with its advanced free form optics. This 9-inch round light features three CREE LED bulbs that produce a powerful white light output, achieving 5700 raw lumens and 2500 effective lumens. The spot beam design focuses the light where it is needed most, enhancing visibility during nighttime driving and adverse weather conditions.

Constructed with a hard coated polycarbonate clear lens and a black fiber reinforced polymer housing, this light is built to withstand harsh environments. The IP67 rating ensures protection against dust and water, making it suitable for various applications. Additionally, the built-in LED light pipe meets ECE requirements, improving daytime visibility and safety.

Installation is straightforward with the included glare shield cap and wiring pigtail with DT connector. The lightweight design and customizable appearance allow for easy integration into any vehicle setup. With a power draw of 4.6 amps at 12 volts and a wattage of 45 watts, the Project X Series One is an efficient choice for enhancing your driving experience.

Features

• Fiber Reinforced Polymer Housing
• Enhanced Free Form "Optic Drive" Technology
• LED Chip Sets Produce An Extremely Efficient Yet Powerful White Light Output
• Series One's Unique Design Creates A Superior Optic In A Lightweight Package That Will Perform In Any Condition
• Signature Built-In LED Light Pipe Meets ECE Requirements For Front Position Light Improving Daytime Driving Visibility And Safety
• Hard Coated Polycarbonate Lens
• Customizable Appearance
• IP67 Rated

Specifications

• Manufacturer: Project X
• Manufacturer Part Number: AL538803-1
• Shape: Round
• Beam Type: Spot Beam
• Diameter: 9 Inch
• Height/ Width: Not Applicable
• Bulb Type: LED
• Light Color: White
• Quantity: Single
• Universality: Fully Universal
• Depth: 5-5/16 Inch
• Wattage: 45 Watt
• Voltage Rating: 12 Volt
• Mounting Style: Surface Mount
• Ampere Rating At 12 Volts: 4.6 Amp
• Lumens: 5700 Raw/ 2500 Effective Lumens
• Bulb Specifications: 3 CREE LED Bulbs
• Lens Material: Polycarbonate
• Housing Color: Black
• Housing Material: Fiber Reinforced Polymer
• Includes: With Glare Shield Cap And Wiring Pigtail With DT Connector
• Estimated Install Time (Hours): 1.5

Technical Documents

• AL538803-1_Install_Guide.pdf
