Advanced charging technology for optimal battery performance and longevity.
The NewMar Phase Three Smart Battery Charger is designed for efficient charging of 12 Volt Gel-Cell, Flooded Lead-Acid, and AGM batteries. This 3-bank charger operates on a wide input voltage range of 90 to 264 Volt AC, making it versatile for various applications. It features a three-stage charging process—Bulk, Absorption, and Float—that ensures rapid recovery and optimal conditioning of batteries, thereby maximizing performance and extending lifespan.
Constructed with a rugged stainless steel case and a durable white powder coat finish, this charger is built to withstand harsh environments. The internal circuitry is coated with polyurethane for enhanced corrosion resistance. The charger includes multiple isolated output banks and an ammeter to indicate total output current, ensuring reliable operation.
An optional temperature compensation sensor adjusts the output voltage based on ambient temperature, further enhancing charging efficiency. The NewMar Phase Three charger is also capable of powering loads without a battery in line, providing flexibility for various power needs. With numerous safety and EMC compliance features, this charger is suitable for industrial, marine, and remote communication applications.
Features
- Built To Last: Rugged Stainless Steel Case With A Durable White Powder Coat Finish With Drip Shield And Polyurethane Coated Internal Circuitry
- Smart Circuitry Provides Three Stage Charging--Bulk, Absorption, Float
- Multiple Isolated Output Banks; Ammeter Indicates Total Output Current
- Optional Sensor Adjusts Output Voltage Based On Battery Temperature
- Current Limiting-Prevents Damage From Overloading
- Charger Status Clearly Displayed With L.E.D., Ammeter, Or Optional Remote Panel
- Use As A Power Supply; Can Power Loads Without A Battery In Line
- Wide Model Range Covers Battery System Ratings From 14 To 950 Ampere Hours
- Numerous Safety And EMC Compliances
Specifications
- Manufacturer: NewMar
- Manufacturer Part Number: PT-80
- Count Of Batteries Charged: 3
- Battery Type: AGM/ Flooded Lead-Acid/ Gel Batteries
- Charging Current: 80 Amp
- Output Voltage: 12 Volt
- Input Voltage: 90 To 264 Volt
- Number Of Stages: 3 Stage
- Universality: Fully Universal
- Length (IN): 5.6 Inch
- Width (IN): 9.6 Inch
- Height (IN): 14.8 Inch
