Newmar Junction Box Thru-Dex BX Series (MPN: BX-3)

Durable and splashproof junction box for reliable electrical connections.

The Newmar Junction Box Thru-Dex BX Series is designed for robust electrical applications, featuring a rugged cast aluminum housing with an enamel finish. Measuring 4.7 inches in width, 3.7 inches in depth, and 1.3 inches in height, this junction box is equipped with a 22 pair terminal strip that accommodates 14 gauge wire, ensuring secure and efficient connections. The IP54 splashproof rating provides protection against water and dust, making it suitable for various environments.

This junction box includes multiple rubber grommet cable entries, allowing for flexible installation options while maintaining a secure seal. The brass compression screw terminals enhance connectivity and reliability, ensuring that electrical connections remain stable over time. Newmar's commitment to quality and customer satisfaction is evident in the design and functionality of this junction box, making it a dependable choice for electrical power distribution.

Features

• Rugged Cast Aluminum Box And Cover With Enamel Finish
• Splash Proof Junction Box With Terminal Strip
• Multiple Rubber Grommet Cable Entries
• Brass Compression Screw Terminals

Specifications

• Manufacturer: NewMar
• Manufacturer Part Number: BX-3
• Dimensions: 4.7 Inch Width X 3.7 Inch Depth X 1.3 Inch Height
• Terminal Strip: 22 Pair
• Wire Gauge: 14
• Protection: IP54 Splashproof
• Color: White
• Material: Aluminum
• Includes: 2 Rubber Grommet Cable Entries

Technical Documents

• Newmar_Junction-Boxes.pdf
