Moroso Performance Oil Pan (MPN: 20449)

Engineered for optimal lubrication in street and strip applications.

The Moroso Performance Oil Pan is designed specifically for Mark IV Big Block Chevy engines, accommodating up to a 4.25 inch stroke with most aluminum rods. This 5 quart capacity oil pan features a wet sump design with a depth of 7-3/4 inches and a length of 9-1/2 inches, ensuring effective oil management during high-performance driving. Constructed from durable steel and finished with a powder-coated black exterior, this oil pan is built to withstand the rigors of both street and strip use.

Precision welding by skilled craftsmen ensures that each Moroso oil pan meets high-quality standards, providing reliability and performance. The internal anti-slosh baffle enhances oil control, reducing the risk of oil starvation during aggressive maneuvers. This oil pan is compatible with both GM 2 bolt and 4 bolt blocks, making it a versatile choice for engine builders looking to optimize their oiling systems.

Moroso's commitment to engineering excellence extends to a wide range of oiling system accessories, allowing for seamless integration with oil pumps, pickups, and other components. This oil pan is designed to work in harmony with Moroso's full line of products, ensuring that users can achieve the best performance from their engines.

Features

• Can Be Used With GM 2 Bolt And 4 Bolt Blocks
• Anti Slosh Internal Baffle
• Accepts Up To 4.25 Inch Stroke With Steel Rods
• OEM Quality Product

Specifications

• Manufacturer: Moroso Performance
• Manufacturer Part Number: 20449
• Recommended Use: Street/ Strip
• Finish: Powder Coated
• Color: Black
• Material: Steel
• Capacity: 5 Quart
• Depth (IN): 7-3/4 Inch
• Baffled: Yes
• Rear Main Seal Style: 2-Piece
• Stroker Clearance: Yes
• Drain Plug Thread Size: 1/2 Inch-20
• Sump Position: Rear
• Sump Style: Wet
• Dipstick Provision: Yes
• Dipstick Location: Passenger Side
• Kicked Out: No
• Kicked Out Position: No Kicked Out
• Includes Pickup: No
• Includes Crank Scraper: No
• Includes Windage Tray: No

Compatibility / Fit

• 1965-1975 Chevrolet Bel Air
• 1900-1900 Chevrolet Big Block 1965-1990 Gen IV
• 1965-1972 Chevrolet Biscayne
• 1973-1974 Chevrolet Blazer
• 1969-1972 Chevrolet Brookwood
• 1975-1980 Chevrolet C10
• 1968-1974 Chevrolet C10 Pickup
• 1968-1980 Chevrolet C10 Suburban
• 1975-1986 Chevrolet C20
• 1968-1974 Chevrolet C20 Pickup
• 1968-1986 Chevrolet C20 Suburban
• 1975-1986 Chevrolet C30
• 1968-1974 Chevrolet C30 Pickup
• 1967-1972 Chevrolet Camaro
• 1966-1976 Chevrolet Caprice
• 1965-1973 Chevrolet Chevelle
• 1968-1968 Chevrolet Chevy II
• 1965-1974 Chevrolet Corvette
• 1966-1975 Chevrolet El Camino
• 1969-1970 Chevrolet Estate
• 1973-1974 Chevrolet G10 Van
• 1976-1976 Chevrolet G20
• 1973-1974 Chevrolet G20 Van
• 1975-1976 Chevrolet G30
• 1973-1974 Chevrolet G30 Van
• 1965-1976 Chevrolet Impala
• 1976-1976 Chevrolet K10
• 1980-1980 Chevrolet K10
• 1968-1974 Chevrolet K10 Pickup
• 1968-1974 Chevrolet K10 Suburban
• 1976-1978 Chevrolet K20
• 1968-1974 Chevrolet K20 Pickup
• 1968-1974 Chevrolet K20 Suburban
• 1985-1985 Chevrolet K20 Suburban
• 1977-1977 Chevrolet K30
• 1980-1986 Chevrolet K30
• 1968-1974 Chevrolet K30 Pickup
• 1976-1978 Chevrolet K5 Blazer
• 1969-1972 Chevrolet Kingswood
• 1973-1975 Chevrolet Laguna
• 1973-1975 Chevrolet Malibu
• 1970-1975 Chevrolet Monte Carlo
• 1969-1972 Chevrolet Nova
• 1973-1973 Chevrolet P10 Van
• 1976-1976 Chevrolet P20
• 1979-1979 Chevrolet P20
• 1970-1971 Chevrolet P20 Van
• 1973-1973 Chevrolet P20 Van
• 1975-1986 Chevrolet P30
• 1970-1971 Chevrolet P30 Van
• 1973-1974 Chevrolet P30 Van
• 1969-1972 Chevrolet Townsman
• 1972-1979 Excalibur Phaeton
• 1975-1978 GMC C15
• 1975-1978 GMC C15 Suburban
• 1968-1974 GMC C15/C1500 Pickup
• 1968-1974 GMC C15/C1500 Suburban
• 1979-1980 GMC C1500
• 1979-1980 GMC C1500 Suburban
• 1975-1978 GMC C25
• 1975-1978 GMC C25 Suburban
• 1968-1974 GMC C25/C2500 Pickup
• 1968-1974 GMC C25/C2500 Suburban
• 1979-1986 GMC C2500
• 1979-1986 GMC C2500 Suburban
• 1975-1978 GMC C35
• 1968-1974 GMC C35/C3500 Pickup
• 1979-1986 GMC C3500
• 1975-1976 GMC G25
• 1976-1976 GMC G35
• 1973-1974 GMC G35/G3500 Van
• 1973-1974 GMC Jimmy
• 1976-1976 GMC Jimmy
• 1976-1976 GMC K15
• 1968-1974 GMC K15/K1500 Pickup
• 1968-1974 GMC K15/K1500 Suburban
• 1980-1980 GMC K1500
• 1976-1978 GMC K25
• 1976-1977 GMC K25 Suburban
• 1968-1974 GMC K25/K2500 Pickup
• 1968-1974 GMC K25/K2500 Suburban
• 1968-1974 GMC K35/K3500 Pickup
• 1979-1986 GMC K3500
• 1979-1979 GMC P1500
• 1970-1971 GMC P25/P2500 Van
• 1975-1978 GMC P35
• 1970-1971 GMC P35/P3500 Van
• 1973-1974 GMC P35/P3500 Van
• 1979-1986 GMC P3500
• 1971-1975 GMC Sprint
• 1969-1974 Iso Grifo

Technical Documents

• unipan_inst.pdf

Product Videos
