Durable nitrogen gas charged shock for improved ride quality and control.
The Monroe Shock Absorber Magnum is engineered to provide enhanced control and comfort for mid to full-size light-duty work trucks and vans. This nitrogen gas charged shock absorber features a sintered iron piston, which offers superior strength and durability compared to traditional metals, ensuring a longer service life. The design includes a 2 inch reserve tube that allows for greater oil capacity, leading to more consistent performance and better heat dissipation than original equipment alternatives.
Incorporating full displaced valving, the Magnum shock absorber delivers an improved valving range during both compression and extension cycles, resulting in a smoother ride. The 1-3/8 inch bore operates at lower pressures than standard units, allowing for more efficient performance with less effort. Additionally, the heavy-duty 5/8 inch piston rod is nitro carburized for enhanced longevity, while the self-lubricating fluid seal minimizes wear and friction, retaining gas effectively.
Designed for all weather conditions, the shock absorber contains special modifiers in its fluid to reduce friction and ensure smooth rod reaction. This product is a single unit, specifically designed for vehicle compatibility, making it a reliable choice for those seeking to maintain optimal tire-to-road contact and improve overall handling.
Features
- All Weather Fluid: Contains Special Modifiers To Reduce Friction And Ensure Smooth Rod Reaction
- Full Displaced Valving For Better Valving Range On Both The Compression And Extension Cycles Of The Unit For A Smooth Comfortable Ride
- Sintered Iron Piston: Stronger Than Traditional Metals, Enhances Durability For Longer Service Life
- Nitrogen Gas Charged For Improved Ride And Handling, Helps Maintain Tire To Road Contact By Reducing Aeration
- 2 Inch Reserve Tube: More Fluid For More Consistent Performance, Greater Oil Capacity To Better Dissipation Of Heat Compared To OE
- 1-3/8 Inch Bore: Lower Operating Pressure Than Standard 1 Inch Bore Units, Work More Efficiently With Less Effort Up To Twice The Fluid Capacity Of Standard 1 Inch Bore Shocks
- 5/8 Inch Piston Rod: Heavy Duty Nitro Carburized Rod For Long Service Life
- Special Seal: Self-Lubricating Fluid Seal Designed To Retain Gas Without Excessive Wear Or Friction
- Designed For Mid To Full-Size Light-Duty Work Trucks And Vans
Specifications
- Manufacturer: Monroe
- Manufacturer Part Number: 153030
- Type: Nitrogen Gas Charged
- With Coil Spring: Yes
- Extended Length (IN): 21.64 Inch
- Compressed Length (IN): 17.17 Inch
- Upper Mounting Style: Strut
- Lower Mounting Style: Eyelet
- Adjustable Valving: No
- Quantity: Single
- Universality: Vehicle Specific
- Internal Design: Twin Tube
- Body Color: Black
- Rod Diameter (IN): 5/8 Inch
- Valving Type: OEM
- Rod Material: Steel
- Body Material: Steel
- With Reservoir: No
- Includes Dust Shield: Yes
- Includes Hardware: No
- Includes Boot: No
- Estimated Install Time (Hours): 0.5
Compatibility / Fit
- 2009-2013 Ford F-150
