Enhanced control and comfort for Thomas School Buses from 1988 to 2006.
The Monroe Gas-Magnum Shock Absorber is designed to provide superior control and comfort for Thomas School Buses manufactured between 1988 and 2006. This shock absorber features an expanded reserve tube that increases oil capacity, allowing for better heat dissipation compared to original equipment. The improved valving range on both compression and extension cycles ensures a smooth and comfortable ride, making it suitable for mid- to full-size light-duty work trucks and vans.
Constructed with a nitrogen gas charge, this shock absorber enhances ride quality and handling by maintaining optimal tire-to-road contact while reducing aeration. The all-weather fluid contains special modifiers that minimize friction, ensuring a smooth rod reaction in various conditions. Additionally, the sintered iron piston offers increased durability, providing a long service life under demanding conditions.
With a 1-3/8 inch bore and a 5/8 inch piston rod, the Monroe Gas-Magnum Shock Absorber operates at lower pressures than standard units, contributing to its consistent performance. The monotube internal design and robust steel construction further enhance its reliability, making it a practical choice for those seeking to replace their shock absorbers with a high-quality, OEM-compatible option.
Features
- Expanded Reserve Tube For Greater Oil Capacity To Better Dissipate Heat Compared To OE; Better Valving Range On Both The Compression And Extension Cycles Of The Unit For A Smooth, Comfortable Ride
- Nitrogen Gas-Charged For Improved Ride And Handling, Helps Maintain Tire-To-Road Contact By Reducing Aeration; Designed For Mid- To Full-Size Light-Duty Work Trucks And Vans
- All Weather Fluid: Contains Special Modifiers To Reduce Friction And Ensure Smooth Rod Reaction
- Full Displaced Valving: Better Valving Range On Both The Compression And Extension Cycles Of The Unit For A Smooth Comfortable Ride
- Sintered Iron Piston: Stronger Than Traditional Metals, Enhances Durability For Long Service Life
- Nitrogen Gas Charged: Nitrogen Gas Charged; 2 Inch Reserve Tube: More Fluid For More Consistent Performance
- 1-3/8 Inch Bore: Lower Operating Pressure Than Standard 1 Inch Bore Units
- 5/8 Inch Piston Rod: Self-Lubricating Fluid Seal Designed To Retain Gas Without Excessive Wear Or Friction
Specifications
- Manufacturer: Monroe
- Manufacturer Part Number: 65490
- Type: Nitrogen Gas Charged
- With Coil Spring: No
- Extended Length (IN): 22.9 Inch
- Compressed Length (IN): 15 Inch
- Upper Mounting Style: Cross Pin
- Lower Mounting Style: Cross Pin
- Adjustable Valving: No
- Quantity: Single
- Universality: Semi-Universal
- Internal Design: Monotube
- Body Color: Yellow
- Rod Diameter (IN): 5/8 Inch
- Valving Type: OEM
- Rod Material: Steel
- Body Material: Steel
- With Reservoir: No
- Includes Dust Shield: Yes
- Includes Hardware: No
- Includes Boot: No
- Estimated Install Time (Hours): 0.5
