Monroe Sensa-Trac Shock Absorber (MPN: 5802)

Advanced shock absorber with position sensitive damping for enhanced ride quality.

The Monroe Sensa-Trac shock absorber is designed for passenger vehicles, featuring position sensitive damping (PSD) technology that enhances ride quality and handling. This shock absorber utilizes a unique groove tube design that acts like an additional stage of valving, allowing for rapid adjustments to changing road conditions and vehicle weight. The nitrogen gas charged design improves ride stability and helps maintain tire contact with the road by reducing aeration.

Constructed with a Fluon banded piston, the Sensa-Trac ensures consistent sealing and durability, while the full displaced valving is specifically tuned for each application to provide optimal performance. The larger bore size compared to standard shocks allows for more efficient control, making it suitable for a variety of driving conditions. Additionally, the shock absorber is equipped with all-weather fluid that minimizes friction for smooth operation.

Features

• All Weather Fluid: Contains Special Modifiers To Reduce Friction And Ensure Smooth Rod Reaction
• Full Displaced Valving: Tuned Specifically For Each Application, This Valving Automatically Adjusts To Road Extremes To Provide Consistency And Ride
• Fluon Banded Piston: The Fluon Band Provides Consistent Sealing Between The Piston And Pressure Tube Which Delivers Better Control And Increased Durability
• Larger Bore Than Most Shocks To Provide More Efficient And Consistent Control
• Unique Groove Tube - PSD: Precision Tapered Grooves In The Pressure Tube Perform Like An Additional Stage Of Valving For Optimum Ride Tuning
• Nitrogen Gas Charged: For Improved Ride And Handling, Helps Maintain Tire To Road Contact By Reducing Aeration - On Most Applications
• Piston Rod: Nitrocarburized Rod For Long Service Life

Specifications

• Manufacturer: Monroe
• Manufacturer Part Number: 5802
• Type: Nitrogen Gas Charged
• With Coil Spring: No
• Extended Length (IN): 20-7/8 Inch
• Compressed Length (IN): 12-3/4 Inch
• Upper Mounting Style: Cross Pin
• Lower Mounting Style: Eyelet
• Adjustable Valving: No
• Quantity: Single
• Universality: Semi-Universal
• Internal Design: Monotube
• Body Color: Black
• Rod Diameter (IN): 1/2 Inch
• Valving Type: Application Specific Valving
• Rod Material: Steel
• Body Material: Steel
• With Reservoir: No
• Includes Dust Shield: Yes
• Includes Hardware: Yes
• Includes Boot: No
• Estimated Install Time (Hours): 0.5

Compatibility / Fit

• 1973-1973 Buick Apollo
• 1971-1973 Buick Centurion
• 1973-1981 Buick Century
• 1971-1981 Buick Electra
• 1970-1981 Buick Estate Wagon
• 1971-1981 Buick LeSabre
• 1973-1987 Buick Regal
• 1971-1978 Buick Riviera
• 1991-1996 Buick Roadmaster
• 1964-1972 Buick Skylark
• 1964-1969 Buick Special
• 1970-1972 Buick Sportwagon
• 1987-1990 Cadillac Brougham
• 1983-1984 Cadillac Commercial Chassis
• 1977-1984 Cadillac DeVille
• 1985-1986 Cadillac Fleetwood
• 1965-1975 Chevrolet Bel Air
• 1965-1972 Chevrolet Biscayne
• 1966-1996 Chevrolet Caprice
• 1964-1973 Chevrolet Chevelle
• 1971-1981 Chevrolet Impala
• 1973-1983 Chevrolet Malibu
• 1970-1988 Chevrolet Monte Carlo
• 1969-1973 Chevrolet Nova
• 1973-1976 Nissan 610
• 1974-1977 Nissan 710
• 1977-1979 Nissan 810
• 1964-1971 Oldsmobile 442
• 1971-1984 Oldsmobile 98
• 1971-1976 Oldsmobile Custom Cruiser
• 1964-1981 Oldsmobile Cutlass
• 1978-1984 Oldsmobile Cutlass Calais
• 1980-1983 Oldsmobile Cutlass Cruiser
• 1975-1980 Oldsmobile Cutlass Salon
• 1985-1987 Oldsmobile Cutlass Salon
• 1967-1988 Oldsmobile Cutlass Supreme
• 1976-1976 Oldsmobile Cutlass Tiara
• 1971-1981 Oldsmobile Delta 88
• 1964-1972 Oldsmobile F85
• 1971-1978 Oldsmobile Toronado
• 1973-1975 Oldsmobile Vista Cruiser
• 1963-1964 Pontiac Bonneville
• 1971-1981 Pontiac Bonneville
• 1963-1964 Pontiac Catalina
• 1971-1981 Pontiac Catalina
• 1973-1975 Pontiac Grand Am
• 1978-1980 Pontiac Grand Am
• 1975-1981 Pontiac Grand LeMans
• 1963-1964 Pontiac Grand Prix
• 1969-1987 Pontiac Grand Prix
• 1971-1978 Pontiac Grand Safari
• 1971-1975 Pontiac Grandville
• 1964-1973 Pontiac GTO
• 1970-1981 Pontiac LeMans
• 1987-1989 Pontiac Safari
• 1963-1964 Pontiac Star Chief
• 1964-1970 Pontiac Tempest
• 1971-1974 Pontiac Ventura

Technical Documents

• TITAN_SAF_5004_NA_200.pdf
