Enhance vehicle stability and comfort with advanced damping technology.
The Monroe Sensa-Trac load adjusting shock absorber is engineered to improve ride quality and handling for light trucks, especially when towing or hauling. Featuring position sensitive damping (PSD) technology, these shock absorbers utilize precision tapered grooves in the pressure tube to adapt to varying road conditions, ensuring consistent performance. The nitrogen gas charged design enhances ride stability by reducing aeration, which helps maintain optimal tire-to-road contact under load.
Constructed with a heavy gauge calibrated coil spring, the Sensa-Trac shock absorbers provide additional control without compromising ride comfort. The Fluon banded piston ensures a reliable seal between the piston and pressure tube, contributing to increased durability and better control. With a load capacity of up to 1,200 pounds, these shock absorbers are suitable for vehicles that frequently carry varying loads or tow trailers, making them a practical choice for demanding applications.
Incorporating features such as all-weather fluid for reduced friction and full displaced valving for automatic adjustment to road extremes, the Monroe Sensa-Trac shock absorbers are designed for maximum performance. The unique groove tube design acts like an additional stage of valving, optimizing ride tuning for enhanced driving experiences. This set of two shock absorbers is a vehicle-specific solution that meets the needs of drivers seeking reliability and improved handling.
Features
- All Weather Fluid: Contains Special Modifiers To Reduce Friction And Ensure Smooth Rod Reaction
- Full Displaced Valving: Tuned Specifically For Each Application, This Valving Automatically Adjusts To Road Extremes To Provide Consistency And Ride
- Fluon Banded Piston: The Fluon Band Provides Consistent Sealing Between The Piston And Pressure Tube Which Delivers Better Control And Increased Durability
- Heavy Gauge Calibrated Coil Spring: Computer Designed For Maximum Performance Without An Increase In Ride Harshness
- Unique Groove Tube - PSD: Precision Tapered Grooves In The Pressure Tube Perform Like An Additional Stage Of Valving For Optimum Ride Tuning
- Nitrogen Gas Charged: For Improved Ride And Handling, Helps Maintain Tire To Road Contact By Reducing Aeration - On Most Applications
- Special Seal: 'Self-Lubricating' Fluid Seal Designed To Retain Gas Without Excessive Wear Or Friction
Specifications
- Manufacturer: Monroe
- Manufacturer Part Number: 58612
- Type: Nitrogen Gas Charged
- With Coil Spring: Yes
- Extended Length (IN): 23-3/4 Inch
- Compressed Length (IN): 14-5/8 Inch
- Upper Mounting Style: Cross Pin
- Lower Mounting Style: Eyelet
- Adjustable Valving: Yes
- Quantity: Set Of 2
- Universality: Vehicle Specific
- Internal Design: Monotube
- Body Color: Black
- Rod Diameter (IN): 5/8 Inch
- Valving Type: Application Specific Valving
- Rod Material: Steel
- Body Material: Steel
- With Reservoir: No
- Includes Dust Shield: Yes
- Includes Hardware: No
- Includes Boot: No
- Estimated Install Time (Hours): 1
Compatibility / Fit
- 1999-2000 Cadillac Escalade
- 1996-2002 Chevrolet Express 2500
- 1996-2002 Chevrolet Express 3500
- 1992-1999 Chevrolet K1500 Suburban
- 1992-1999 Chevrolet K2500 Suburban
- 1995-2000 Chevrolet Tahoe
- 1992-1999 GMC K1500 Suburban
- 1992-1999 GMC K2500 Suburban
- 1996-2002 GMC Savana 2500
- 1996-2002 GMC Savana 3500
- 1995-2000 GMC Yukon
