Enhance towing and hauling capabilities with adjustable air support.
The Monroe Max-Air Shock Absorber is engineered for vehicles that frequently tow trailers or carry heavy loads. This hydraulic shock absorber features an adjustable air chamber that allows inflation from 20 PSI to 150 PSI, ensuring that the vehicle maintains a level height under load. The design is optimized for performance, with a focus on durability and smooth operation, making it suitable for demanding applications.
Constructed with all-weather fluid that minimizes friction, the Max-Air Shock Absorber provides a comfortable ride by utilizing full displaced valving for both compression and extension cycles. The sintered iron piston enhances strength and longevity, while the lubricated air sleeve reduces friction, contributing to a longer service life. This shock absorber is designed to be vehicle specific, ensuring compatibility and optimal performance.
Installation is straightforward, with a set of two shock absorbers included, and it comes with necessary hardware for mounting. The robust construction features a black steel body and a 1/2 inch iron rod, ensuring reliability under various driving conditions. The Max-Air Shock Absorber is a practical solution for those needing enhanced suspension support for towing and hauling tasks.
Features
- All Weather Fluid Contains Special Modifiers To Reduce Friction And Ensure Smooth Rod Reaction
- Full Displaced Valving Range On Both The Compression And Extension Cycles Of The Unit For A Smooth Comfortable Ride
- Large Volume Air Chamber Inflates Up To 150 PSI With Vehicle Loaded. Deflates For Normal Driving
- Lubricated Air Sleeve Reduces Friction For Longer Service Life. Provides Smoother Operation During Suspension Movement
- Sintered Iron Piston Stronger Than Traditional Metals, Enhances Durability For Longer Service Life
- Special Air Fitting To Resists Air Leakage
Specifications
- Manufacturer: Monroe
- Manufacturer Part Number: MA819
- Type: Hydraulic
- With Coil Spring: No
- Extended Length (IN): 21-1/4 Inch
- Compressed Length (IN): 13-3/8 Inch
- Upper Mounting Style: Cross Pin
- Lower Mounting Style: Eyelet
- Adjustable Valving: Yes
- Quantity: Set Of 2
- Universality: Vehicle Specific
- Internal Design: Monotube
- Body Color: Black
- Rod Diameter (IN): 1/2 Inch
- Valving Type: Velocity Proportional Valving
- Rod Material: Iron
- Body Material: Steel
- With Reservoir: No
- Includes Dust Shield: Yes
- Includes Hardware: Yes
- Includes Boot: No
- Estimated Install Time (Hours): 1
Compatibility / Fit
- 1992-1996 Buick Roadmaster
- 1991-1992 Cadillac Brougham
- 1992-1996 Cadillac Commercial Chassis
- 1993-1996 Cadillac Fleetwood
- 1982-1996 Chevrolet Caprice
