Enhanced performance for mid to full size trucks and vans.
The Monroe Gas-Magnum shock absorber is engineered specifically for mid to full size pick-up trucks and vans, providing a balance of firm control and comfort. This nitrogen gas charged unit features a lower operating pressure than standard 1 inch bore shocks, allowing for improved efficiency and reduced wear. With an expanded reserve tube, it offers greater oil capacity which aids in heat dissipation, ensuring consistent performance under various driving conditions.
Constructed with a heavy-duty nitro carburized piston rod, the Monroe Gas-Magnum is designed for longevity and reliability. The all-weather fluid used in this shock absorber contains special modifiers that minimize friction, promoting smooth rod reaction. Additionally, the full displaced valving enhances the valving range during both compression and extension cycles, contributing to a smoother ride.
The sintered iron piston provides superior strength compared to traditional metals, further enhancing the durability of the shock absorber. This unit is designed to maintain optimal tire to road contact by reducing aeration, which improves overall ride and handling. The Monroe Gas-Magnum shock absorber is a robust solution for those seeking reliable performance in demanding driving environments.
Features
- Bore: Lower Operating Pressure Than Standard 1 Inch Bore Units. Special Seal: 'Self-Lubricating' Fluid Seal Designed To Retain Gas Without Excessive Wear Or Friction
- Reserve Tube: More Fluid For More Consistent Performance. Expanded Reserve Tube For Greater Oil Capacity To Better Dissipate Heat
- Piston Rod: Heavy-Duty Nitro Carburized Rod For Long Service Life. Work More Efficiently With Less Effort
- All Weather Fluid: Contains Special Modifiers To Reduce Friction And Ensure Smooth Rod Reaction
- Full Displaced Valving: Better Valving Range On Both The Compression And Extension Cycles Of The Unit For A Smooth Comfortable Ride
- Nitrogen Gas Charged: For Improved Ride And Handling, Helps Maintain Tire To Road Contact By Reducing Aeration
- Sintered Iron Piston: Stronger Than Traditional Metals, Enhances Durability For Longer Service Life
Specifications
- Manufacturer: Monroe
- Manufacturer Part Number: 34798
- Type: Nitrogen Gas Charged
- With Coil Spring: No
- Extended Length (IN): 16-1/2 Inch
- Compressed Length (IN): 11-3/8 Inch
- Upper Mounting Style: Eyelet
- Lower Mounting Style: Eyelet
- Adjustable Valving: No
- Quantity: Single
- Universality: Vehicle Specific
- Internal Design: Monotube
- Body Color: Yellow
- Rod Diameter (IN): 5/8 Inch
- Valving Type: Application Specific Valving
- Rod Material: Iron
- Body Material: OEM
- With Reservoir: No
- Includes Dust Shield: Yes
- Includes Hardware: No
- Includes Boot: No
- Estimated Install Time (Hours): 0.5
Compatibility / Fit
- 1999-2000 Cadillac Escalade
- 1992-1994 Chevrolet Blazer
- 1988-1999 Chevrolet K1500
- 1992-1999 Chevrolet K1500 Suburban
- 1988-2000 Chevrolet K2500
- 1992-1999 Chevrolet K2500 Suburban
- 1995-2000 Chevrolet Tahoe
- 1988-1999 GMC K1500
- 1992-1999 GMC K1500 Suburban
- 1988-2000 GMC K2500
- 1992-1999 GMC K2500 Suburban
- 1992-2000 GMC Yukon
