Efficient cooling for high-performance charge-air systems up to 1500 horsepower.
The Mishimoto Universal Air-to-Water Heat Exchanger is engineered to provide effective cooling support for charge-air cooling systems, accommodating builds up to 1500 horsepower. With overall dimensions of 24.46 inches in length, 16.85 inches in height, and 2.51 inches in depth, this heat exchanger features a dual core design that maximizes flow and heat dissipation. Constructed from all-aluminum materials, it ensures superior strength and durability, making it suitable for high-performance applications.
This heat exchanger is designed with precision TIG-welded end tanks that enhance durability and pressure tolerance. The robust half-inch thick universal mounting bosses on each end tank facilitate easy installation, while the bead rolled 3/4 inch inlet and outlet provide a leak-free connection. The strategically designed three-row core optimizes cooling efficiency, making it a reliable choice for forced induction builds.
Mishimoto offers a complete line of air-to-water products, ensuring that you have everything needed to build an effective air-to-water intercooler system. This heat exchanger is a critical component for maintaining optimal temperatures in turbocharged vehicles, contributing to improved performance and reliability.
Features
- Universal Heat Exchanger For Use With Air To Water Intercooler Systems
- Provides Effective Cooling Support For Charge Air Cooling Systems Up To 500 Horsepower
- Strategically Designed 3 Row Core Offers Maximum Flow And Heat Dissipation
- All Aluminum Construction Yields Superior Strength And Durability
- Precision TIG Welded End Tanks For Improved Durability And Pressure Tolerance
- Robust 1/2 Inch Thick Universal Mounting Bosses On Each End Tank
- Bead Rolled 3/4 Inch Inlet And Outlet Provide A Leak-Free Connection
- Multiple Sizes To Choose From To Fit The Needs Of Your Project
Specifications
- Manufacturer: Mishimoto
- Manufacturer Part Number: MMRAD-HE-03
- Overall Length (IN): 24.46 Inch
- Overall Height (IN): 16.85 Inch
- Overall Depth (IN): 2.51 Inch
- Core Rows: Dual
- Core Material: Aluminum
- Inlet Size (IN): 3/4 Inch
- Outlet Size (IN): 3/4 Inch
- Color: Silver
- Core Length (IN): 19.68 Inch
- Core Height (IN): 15.98 Inch
- Core Depth (IN): 1.88 Inch
- Tank Material: Aluminum
