High-performance intercooler for turbocharged and supercharged engines.
The Mishimoto R-Line intercooler is engineered to provide optimal cooling capacity for turbocharged and supercharged vehicles. Constructed from 6061 aircraft-quality aluminum, this intercooler is designed for durability and efficiency, effectively reducing induction air temperatures to enhance engine performance. With a maximum flow rate of 1250 CFM, the intercooler features a robust bar-and-plate core that ensures superior heat transfer while maintaining high boost pressures.
Measuring 31 inches in width, 12 inches in height, and 4 inches in thickness, the intercooler is equipped with a massive 4-inch thick core and 3-inch inlet and outlet sizes, allowing for optimal airflow and volume necessary for high horsepower applications. The precision TIG welded construction further enhances its performance capabilities, making it a reliable choice for those seeking to increase horsepower safely.
Mishimoto also offers a free replacement policy for accidental damages, providing peace of mind for users. This intercooler is finished in a sleek silver powder coat, ensuring both aesthetic appeal and protection against the elements. The Mishimoto R-Line intercooler is a critical component for any performance-focused vehicle, delivering the cooling efficiency required for demanding driving conditions.
Features
- Durable Bar-and-plate Core Provides Superior Heat Transfer While Effectively Reducing Aits
- Robust, One-piece Cast Aluminum End Tanks Withstand High Boost Pressures
- Massive 4 Inch Thick Core And 3 Inch Inlet Or Outlet Provides Optimal Flow And Volume For High Horsepower Vehicles
- Free Replacement For Accidental Damages
Specifications
- Manufacturer: Mishimoto
- Manufacturer Part Number: MMINT-UR
- Type: Air To Air
- Maximum Horsepower (HP): 1000 Horsepower
- Flow Rate: 1250 Cubic Feet Per Minute
- Overall Width (IN): 31 Inch
- Overall Height (IN): 12 Inch
- Overall Depth (IN): 4 Inch
- Construction: Bar And Plate
- Inlet Size (IN): 3 Inch
- Outlet Size (IN): 3 Inch
- Core Width (IN): 23 Inch
- Core Height (IN): 12 Inch
- Core Depth (IN): 4 Inch
- Inlet/Outlet Neck Location: Center
- Finish: Powder Coated
- Color: Silver
- Material: Aluminum
Technical Documents
Product Videos
Shipping & Returns
- This product ships within the continental USA only.
- This product typically ships within 1 to 3 business days.
- Returns are accepted within 30 days for items in like-new condition. For complete details, please see our return policy.
