Mickey Thompson Classic Pro Wheel (MPN: 274508)

Timeless design meets modern performance for versatile applications.

The Mickey Thompson Classic Pro Wheel features a 20 inch diameter and 9 inch width, designed for a variety of modern vehicles. Its 8-hole design is inspired by the Classic III, offering a street-style simulated beadlock that enhances both aesthetics and functionality. Constructed from one-piece cast aluminum, this wheel is finished in satin bronze with a black simulated beadlock ring, providing a robust and stylish appearance.

With a load capacity of 2500 pounds, the Classic Pro Wheel is engineered to support heavy-duty applications while maintaining compatibility with Tire Pressure Monitoring Systems (TPMS). The wheel's 60 degree conical seat lug nut design ensures a secure fit, while the valve stem niche cut out allows for easy access. The modern low profile cap design, featuring an embossed M/T logo, adds a distinctive touch to the overall look.

This wheel accommodates a maximum tire diameter of 40 inches and offers a backspacing of 5.00 inches with a 0 millimeter offset. The center bore measures 110.10 millimeters, making it suitable for a wide range of vehicles. The Mickey Thompson Classic Pro Wheel is a reliable choice for those seeking a blend of classic style and contemporary performance.

Features

• Simulated Beadlock Style With Genuine 5/8 Inch Zinc Bolts For A Classic And Commanding Look
• Valve Stem Niche Cut Out For Easy Access
• Modern Low Profile Cap Design
• Vast Fitments For Most Modern Vehicles

Specifications

• Manufacturer: Mickey Thompson Wheel
• Manufacturer Part Number: 274508
• Bolt Pattern Inch: Not Applicable
• Bolt Pattern Millimeter: Not Applicable
• Diameter: 20
• Width: 9
• Offset: 0
• Backspacing: 5.00
• Finish: Painted Satin
• Color: Bronze With Black Simulated Beadlock Ring
• Material: Aluminum
• Bolt Pattern Inch: 5x5.90
• Bolt Pattern Inch: Not Applicable
• Bolt Pattern Millimeter: 5x150
• Bolt Pattern Millimeter: Not Applicable
• Lug Nut Seat Type: 60 Degree Conical
• Center Caps Included: Yes
• Center Bore: 110.10
• Lug Nut Design: Acorn
• Compatible With TPMS (Tire Pressure Monitoring Sys: Yes
• Basic Design: 8 Hole
• With Inserts: No
• Load Capacity: 2500
• Size: 20x9
• Max Tire Diameter: 40
• Center Cap Design: Embossed M/T Logo
• Finish Warranty: 1 Year
• Structural Warranty: Lifetime
• Quantity: Single
• Construction: One Piece Cast
• With Hub Centric Ring: No
• Estimated Install Time (Hours): 0.5

Compatibility / Fit

• 2007-2021 Toyota Tundra

Technical Documents

• Mickey_Thompson___Warranty_Info.pdf
