Combining vintage design with modern engineering for trucks and SUVs.
The Mickey Thompson Canyon Wheel features a 17 inch diameter and 9 inch width, designed specifically for trucks and SUVs. This wheel showcases a classic 2-step lip design that pays homage to the vintage Medallion-inspired style while incorporating modern engineering techniques. With a robust 5-hole slot configuration, it provides a tough and aggressive aesthetic that enhances the overall look of both classic and contemporary vehicles.
Constructed from one-piece cast aluminum, the Canyon Wheel is polished for a sleek finish and offers a load capacity of 2500 pounds. It is compatible with Tire Pressure Monitoring Systems (TPMS) and accommodates a maximum tire diameter of 40 inches. The wheel features a 60 degree conical seat lug nut design and an embossed M/T logo center cap, ensuring both functionality and style. This wheel is an excellent choice for those looking to enhance their vehicle's performance and appearance.
Features
- Classic 2-Step Lip Design
- Reimagined 1960’s Mickey Thompson Wheel Style For Today’s Modern Rigs
- 5-Hole Slot For A Tough, Aggressive Look
- For Classic And Modern Trucks And SUVs
Specifications
- Manufacturer: Mickey Thompson Wheel
- Manufacturer Part Number: 274634
- Bolt Pattern Inch: Not Applicable
- Bolt Pattern Millimeter: Not Applicable
- Diameter: 17
- Width: 9
- Offset: -12
- Backspacing: 4.53
- Finish: Polished
- Color: Natural
- Material: Aluminum
- Bolt Pattern Inch: 5x5.50
- Bolt Pattern Inch: Not Applicable
- Bolt Pattern Millimeter: 5x139.7
- Bolt Pattern Millimeter: Not Applicable
- Lug Nut Seat Type: 60 Degree Conical
- Center Caps Included: Yes
- Center Bore: 108.10
- Lug Nut Design: Acorn
- Compatible With TPMS (Tire Pressure Monitoring Sys: Yes
- Basic Design: 5 Hole
- With Inserts: No
- Load Capacity: 2500
- Size: 17x9
- Max Tire Diameter: 40
- Center Cap Design: Embossed M/T Logo
- Finish Warranty: 1 Year
- Structural Warranty: Lifetime
- Quantity: Single
- Construction: One Piece Cast
- With Hub Centric Ring: No
- Estimated Install Time (Hours): 0.5
Technical Documents
Shipping & Returns
- This product ships within the continental USA only.
- This product typically ships within 1 to 3 business days.
- Returns are accepted within 30 days for items in like-new condition. For complete details, please see our return policy.
