Mickey Thompson Canyon Pro Wheel (MPN: 274676)

Durable 18 Inch Wheel with Modern Race-Inspired Design

The Mickey Thompson Canyon Pro Wheel is engineered for trucks and SUVs, offering a blend of modern aesthetics and robust functionality. With an 18 inch diameter and 9 inch width, this wheel features a 5-hole slot design complemented by a simulated beadlock, enhancing both style and performance. Constructed from one-piece cast aluminum, it provides a high load capacity of 2500 pounds, ensuring strength and durability for demanding applications.

Designed with a 6 x 135 millimeter bolt pattern and a 60 degree conical seat lug, the Canyon Pro Wheel is compatible with a wide range of modern vehicles. The satin bronze finish, paired with a black simulated beadlock ring, not only adds to its visual appeal but also withstands the rigors of everyday use. The wheel includes a valve stem niche cut out for easy access and features a modern low profile cap design, making it a practical choice for vehicle owners.

Additionally, the Canyon Pro Wheel is compatible with Tire Pressure Monitoring Systems (TPMS), enhancing safety and convenience. With a maximum tire diameter of 38 inches, this wheel is suitable for various tire sizes, making it a versatile option for those looking to enhance their vehicle's performance and appearance.

Features

• Simulated Beadlock Style With Genuine 5/8 Inch Zinc Bolts For A Classic And Commanding Look
• Valve Stem Niche Cut Out For Easy Access
• Modern Low Profile Cap Design
• Vast Fitments For Most Modern Vehicles
• High Load Rating For Strength And Durability

Specifications

• Manufacturer: Mickey Thompson Wheel
• Manufacturer Part Number: 274676
• Bolt Pattern Inch: Not Applicable
• Bolt Pattern Millimeter: Not Applicable
• Diameter: 18
• Width: 9
• Offset: 0
• Backspacing: 5.00
• Finish: Painted Satin
• Color: Bronze With Black Simulated Beadlock Ring
• Material: Aluminum
• Bolt Pattern Inch: 6x5.31
• Bolt Pattern Inch: Not Applicable
• Bolt Pattern Millimeter: 6x135
• Bolt Pattern Millimeter: Not Applicable
• Lug Nut Seat Type: 60 Degree Conical
• Center Caps Included: Yes
• Center Bore: 87.10
• Lug Nut Design: Acorn
• Compatible With TPMS (Tire Pressure Monitoring Sys: Yes
• Basic Design: 5 Hole
• With Inserts: No
• Load Capacity: 2500
• Size: 18x9
• Max Tire Diameter: 38
• Center Cap Design: Embossed M/T Logo
• Finish Warranty: 1 Year
• Structural Warranty: Lifetime
• Quantity: Single
• Construction: One Piece Cast
• With Hub Centric Ring: No
• Estimated Install Time (Hours): 0.5

Compatibility / Fit

• 2022-2026 Ford Bronco
• 2016-2019 Ford Expedition
• 2021-2026 Ford Expedition
• 2004-2026 Ford F-150

Technical Documents

• Mickey_Thompson___Warranty_Info.pdf
