High-performance aluminum wheel with advanced engineering for durability and strength.

The Method Race Wheels 803 Raised is a 20 inch diameter wheel designed for high-performance applications. Constructed from lightweight aluminum, this wheel features a gloss titanium finish that enhances its aesthetic appeal while providing durability. With a load capacity of 2650 pounds, it is engineered to withstand the demands of powerful vehicles, making it suitable for both on-road and off-road use.

This wheel is compatible with Tire Pressure Monitoring Systems (TPMS) and features a 6 x 135 millimeter bolt pattern, 12 millimeter offset, and 5.44 inch backspacing. The design includes a 60 degree conical seat lug and a large machined smooth radius in the bead flange, which aids in tire mounting and minimizes the risk of tire damage. The 6 split spoke design not only contributes to its visual appeal but also enhances performance.

Method Race Wheels employs a proprietary manufacturing process that includes forging from a solid block of 6061 billet aluminum, followed by heat treatment to a T6 standard for ultimate tensile strength. This results in a wheel that is both stronger and lighter than those produced through conventional methods. Each wheel undergoes rigorous lab and real-world testing to ensure reliability and performance before reaching the market.

Features

  • Gloss Titanium Finish
  • Constructed From Aluminum
  • Compatible With Tire Pressure Monitoring System
  • Large Machined Smooth Radius In The Bead Flange Aids In Outer Bead Tire Mounting And Eliminates Any Possibilities Of Harmful Cuts To The Tire
  • Select Method Beadlock Wheels Feature Circular Pockets Machined Into The Beadlock Flange For Added Grip Of The Tire Bead To Eliminate Tire Rotation On Powerful High-Torque Producing Vehicles
  • Redundant Sets Of Threaded Beadlock Ring Mounting Holes On Select Method Beadlock Wheels Allow For Continued Wheel Use In The Event Of Thread Stripping Or Elevated Impact Damage
  • Heat-Treated To A T6 Standard For Ultimate Tensile Strength
  • Both Stronger And Lighter Than Conventional Manufacturing Processes

Specifications

  • Manufacturer: Method Race Wheels
  • Manufacturer Part Number: MR80329016812
  • Bolt Pattern Inch: Not Applicable
  • Bolt Pattern Millimeter: Not Applicable
  • Diameter: 20
  • Width: 9
  • Offset: 12
  • Backspacing: 5.44
  • Finish: Painted Gloss
  • Color: Titanium
  • Material: Aluminum
  • Bolt Pattern Inch: 6x5.31
  • Bolt Pattern Inch: Not Applicable
  • Bolt Pattern Millimeter: 6x135
  • Bolt Pattern Millimeter: Not Applicable
  • Lug Nut Seat Type: 60 Degree Conical
  • Center Caps Included: No
  • Center Bore: 87.00
  • Lug Nut Design: Acorn
  • Compatible With TPMS (Tire Pressure Monitoring Sys: Yes
  • Basic Design: 6 Split Spoke
  • With Inserts: No
  • Load Capacity: 2650
  • Size: 20x9
  • Max Tire Diameter: 40
  • Center Cap Design: Method Race Wheel Logo
  • Quantity: Single
  • With Hub Centric Ring: No
  • Estimated Install Time (Hours): 0.5

Compatibility / Fit

  • 2004-2019 Ford F-150
