Advanced ultrasonic technology for accurate gasoline level monitoring.
Maretron's tank monitor system utilizes advanced ultrasonic technology to accurately sense gasoline fluid levels in tanks. This system is designed to monitor tanks with a depth of up to 24 inches, providing reliable readings without the complications of long probes that can corrode or foul. The ultrasonic sensor transmits sound waves from the top of the tank, measuring the time it takes for the waves to return, which allows for precise fluid level calculations.
The tank monitor system is compatible with NMEA 2000 networks, enabling users to view tank levels on any NMEA 2000 compatible display, such as Maretron's N2KView vessel monitoring system. This feature enhances convenience and accessibility, allowing for real-time monitoring from various locations on the vessel. Additionally, the system can be calibrated for irregularly shaped tanks, accommodating up to 16 tanks per tank type, ensuring accurate readings regardless of tank design.
With a robust operating temperature range and IP67 waterproof rating, the Maretron tank monitor system is built to withstand harsh marine environments. It also includes reverse battery protection and load dump protection, ensuring durability and reliability in various conditions. This system is an essential tool for effective fuel management and monitoring in marine applications.
Features
- Transmits Liquid Levels Over An NMEA 2000 Interface
- Integrated Ultrasonic Level Sensor
- Can Be Used In Tanks Up To 24 Inch Deep
- SAE J1810 5-Hole, 1-1/2 Inch NPT, Or 1-1/4 Inch BSP Mounting
- Accommodates Irregularly Shaped Tanks With 16 Point Calibration
- Programmable Tank Number Up To 16 Per Tank Type
- Programmable Tank Capacity
Specifications
- Manufacturer: Maretron
- Manufacturer Part Number: TLM150-01
- Used For: Monitor Level For Gasoline Tanks Up To 24 Inch Depth
- Display Type: No Display
- Panel Size: Not Applicable
- Capacity: Measures Up To 16 Tanks
- With Alarm: No
- With Tank Sensor: Yes
- With Connector: Yes
