Icon Vehicle Dynamics Compression Wheel (MPN: 2018907345SB)

Enhance your vehicle's performance with optimized design and durability.

The Icon Vehicle Dynamics Compression Wheel is engineered for performance and style, featuring an 18-inch diameter and 9-inch width. Constructed from a single piece of cast aluminum, this wheel offers a satin black finish that enhances the aesthetic appeal of any Jeep, truck, or SUV. With a load capacity of 2750 pounds, it is designed to withstand rigorous driving conditions while maintaining structural integrity.

This wheel is compatible with Tire Pressure Monitoring Systems (TPMS) and features a 60-degree conical seat lug for secure fitment. The optimized backspacing of 4.53 inches and a -12 millimeter offset improve handling and ride quality by reducing scrub radius. The 12 spoke design not only adds to the visual appeal but also contributes to reduced unsprung weight, enhancing both on and off-road performance.

The Compression Wheel is designed with application-specific dimensions to maximize caliper clearance and ensure unimpeded suspension travel. This makes it an excellent choice for those looking to complement their vehicle with an ICON Vehicle Dynamics suspension system. The included Icon Vehicle Dynamics logo center cap adds a touch of branding to the overall design.

Features

• Satin Black Finish
• 1 Piece Cast Aluminum Construction
• Compatible With Tire Pressure Monitoring System
• With Icon Vehicle Dynamics Logo Center Cap
• Application-Specific Dimensions Optimize Vehicle Dynamics And Tire Clearance
• Reduced Unsprung Weight And Rotating Mass Improves On And Off-Road Vehicle Performance

Specifications

• Manufacturer: Icon Vehicle Dynamics
• Manufacturer Part Number: 2018907345SB
• Bolt Pattern Inch: Not Applicable
• Bolt Pattern Millimeter: Not Applicable
• Diameter: 18
• Width: 9
• Offset: -12
• Backspacing: 4.53
• Finish: Painted Satin
• Color: Black
• Material: Aluminum
• Bolt Pattern Inch: 5x5.00
• Bolt Pattern Inch: Not Applicable
• Bolt Pattern Millimeter: 5x127
• Bolt Pattern Millimeter: Not Applicable
• Lug Nut Seat Type: 60 Degree Conical
• Center Caps Included: Yes
• Center Bore: 71.50
• Lug Nut Design: Acorn
• Compatible With TPMS (Tire Pressure Monitoring Sys: Yes
• Basic Design: 12 Spoke
• With Inserts: No
• Load Capacity: 2750
• Size: 18x9
• Max Tire Diameter: 38
• Center Cap Design: Icon Vehicle Dynamics Logo
• Finish Warranty: 2 Years
• Structural Warranty: Lifetime
• Quantity: Single
• Construction: One Piece Cast
• With Hub Centric Ring: No
• Estimated Install Time (Hours): 0.5

Compatibility / Fit

• 1959-1964 Buick Electra
• 1962-1970 Buick Wildcat
• 1988-1992 Cadillac Brougham
• 1970-1974 Cadillac DeVille
• 1970-1972 Chevrolet Brookwood
• 1980-1990 Chevrolet Caprice
• 1967-1969 GMC C15/C1500 Pickup
• 1987-1987 GMC R1500
• 2020-2025 Jeep Gladiator JT
• 2007-2018 Jeep Wrangler JK
• 2018-2025 Jeep Wrangler JL

Technical Documents

• ICON_Warranty_2023_1730.pdf
