Advanced sonar technology for clear fish detection and structure imaging.
The Garmin Transom Mount Transducer is designed for coastal and offshore anglers seeking high-performance sonar capabilities. This 8-pin transducer utilizes Mid-Band CHIRP technology, operating within a frequency range of 85-165 kHz, to deliver exceptional clarity and target separation. With a power rating of 600 watts for traditional sonar and 500 watts for ClearVü, it provides reliable depth readings up to 1800 feet for traditional sonar and 1000 feet for ClearVü imaging.
Engineered for versatility, the transducer supports a transom angle of 0 to 70 degrees, ensuring optimal performance across various boat types. The 30-foot cable allows for flexible installation, and the included installation instructions facilitate a straightforward setup process. The transducer's beamwidth of 24-13 degrees for traditional sonar and 2.5x51, 1.4x29 degrees for ClearVü enhances the ability to visualize underwater structures and fish with precision.
Garmin's commitment to innovation is evident in this transducer, which combines essential utility with advanced technology to meet the demands of serious anglers. The clear and crisp fish arches displayed by this transducer enable users to make informed decisions while fishing, enhancing the overall experience on the water.
Features
- Perfect For Coastal And Offshore Anglers Who Want CHIRP Traditional Sonar And CHIRP ClearVu Scanning Sonar
- Transom Mounted Transducer Consistently Displays Clear And Crisp Fish Arches With Superior Target Separation As Well As Clear Definition Of Structure Below The Boat
- 8-Pin Transducer Features Mid-Band Chirp Traditional Sonar And Has A Power Rating Of 600 Watt
- Provides A Installation Instructions
Specifications
- Manufacturer: Garmin
- Manufacturer Part Number: 010-12404-00
- Mounting Location: Transom Mount
- Number Of Pins: 8 Pin
- Depth: 1800 Feet For Traditional And 1000 Feet For ClearVü
- Power Rating: 600 Watt For Traditional And 500 Watt For ClearVü
- Frequency Range: 85-165 kHz Mid CHIRP Operating Frequency
- Supported Angle: 0 To 70 Degree Transom Angle
- Cable Length: 30 Feet
