Efficiently manage your boat's lighting with advanced control features.
The Garmin Light Control Module is designed to provide seamless control over various lighting groups on your boat, including cup holders, speakers, strip lights, and courtesy lights. This module operates within a voltage range of 10.8 to 16 volts for 12-volt systems and 21.6 to 32 volts for 24-volt systems, ensuring compatibility with a wide range of marine electrical setups. With a compact size of 7.76 inches in width, 1.85 inches in depth, and 2.05 inches in height, it can be easily integrated into your existing system without taking up excessive space.
This module features a robust design with an IP66/IP67 water rating, making it suitable for the harsh marine environment. It operates effectively within a temperature range of 32 to 122 degrees Fahrenheit and includes essential safety features such as over voltage and over current protection. The system is scalable, allowing for the addition of more lights after the initial installation, and can be controlled via the NMEA 2000 network or the ActiveCaptain app on compatible smartphones.
The Garmin Light Control Module also includes a plug-and-play connection type, making installation straightforward. It comes with a tee connector, mounting screws, and three LED flying leads with water-resistant six-way connectors, ensuring a secure and reliable setup. This module not only enhances the aesthetic appeal of your boat but also provides practical functionality for managing lighting effectively.
Features
- Be The Light DJ: From Bow To Stern And Everything In Between, This Module Lets You Control And Set Up Different Light Groups And Scenes
- In Your Control: Control Lights Over The NMEA 2000 Network With Your Compatible Chartplotter Or With The Activecaptain App On Your Compatible Smartphone
- Match The Beat: See The Beat By Syncing The LED Lights To The Music Track With The Audio Sync Feature
- Grow The System: Add More Lights After The Initial Install With A Scalable System
- Rugged Design: Built To Withstand The Abuse Of Life On The Water
Specifications
- Manufacturer: Garmin
- Manufacturer Part Number: 010-02830-00
- Ampere: 6 Amp
- Connection Type: Plug And Play
- Dimensions: 7.76 Inch Width x 1.85 Inch Depth x 2.05 Inch Height
- Color: Black
- Waterproof Rating: IP66/ IP67 Water Rating
- Includes: With Tee Connector/Mounting Screws/Three LED Flying Leads With Water Resistant Six Way Connectors
Technical Documents
Product Videos
Shipping & Returns
- This product ships within the continental USA only.
- This product typically ships within 1 to 3 business days.
- Returns are accepted within 30 days for items in like-new condition. For complete details, please see our return policy.
