Advanced shock technology for enhanced ride quality and handling.
The Fox Shocks Performance Series 2.0 IFP shock is engineered to elevate the performance of trucks and SUVs. Utilizing a hydraulic and nitrogen gas charged design, this shock features an Internal Floating Piston (IFP) mono-tube structure that effectively separates shock oil from the gas chamber, preventing oil aeration and ensuring consistent performance. The precision valving is factory-tuned to deliver a smooth on-road experience while maintaining predictable handling in off-road conditions.
Constructed from 6061-T6 aluminum, the 2.0 inch body is impact extruded and CNC machined, providing durability and resistance to rust over time. The shock is equipped with a race-developed high-flow damping piston and a redundant sealing pack system that enhances longevity and performance. The use of JM92 advanced suspension fluid allows for optimal performance across varying temperatures, making this shock suitable for diverse driving environments.
With a compressed length of 17.65 inches and an extended length of 28.72 inches, the shock is designed for vehicle-specific applications. The non-adjustable valving and robust construction ensure reliability and performance, making the Fox Shocks Performance Series 2.0 IFP an essential component for those seeking to improve their vehicle's suspension system.
Features
- Body : 2.0 Inch Impact Extruded And CNC Machined 6061-T6 Clear Anodized Aluminum One-Piece Body Resists Rust Over Time
- Body Plating : Clear-Anodized For A Durable Finish
- Reservoir : Internal IFP Mono-Tube Reservoir Design
- Components: Black-Anodized, CNC-Machined 6061-T6 Billet Aluminum
- Shaft : 5/8 Inch Hard Chrome Plated Heat-Treated Alloy Steel
- Piston : Race-Developed High-Flow Piston Design
- Seals : Redundant Sealing Pack System Main Seal, Wiper Seal, Scraper Seal
- Oil : JM92 Advanced Suspension Fluid For Improved Performance At Variable Temperatures
- Bushing : Quiet Nitrile Rubber Allows For Increased Suspension Articulation
Specifications
- Manufacturer: Fox Shocks
- Manufacturer Part Number: 985-24-201
- Type: Hydraulic/ Nitrogen Gas Charged
- With Coil Spring: No
- Extended Length (IN): 28.72 Inch
- Compressed Length (IN): 17.65 Inch
- Upper Mounting Style: Stud
- Lower Mounting Style: Eyelet
- Adjustable Valving: No
- Quantity: Single
- Universality: Vehicle Specific
- Internal Design: Monotube
- Body Color: Silver
- Rod Diameter (IN): 5/8 Inch
- Valving Type: Non Adjustable Valving
- Rod Material: Steel
- Body Material: Aluminum
- With Reservoir: No
- Includes Dust Shield: No
- Includes Hardware: No
- Includes Boot: Yes
- Estimated Install Time (Hours): 0.5
Compatibility / Fit
- 2015-2016 Ram 2500
- 2019-2025 Ram 2500
- 2014-2014 Ram 3500
- 2018-2018 Ram 3500
- 2021-2025 Ram 3500
