Advanced damping technology for enhanced vehicle performance and comfort.
The FOX Factory Series Internal Bypass shock is engineered to deliver superior damping performance through its patented position sensitive technology. This innovative design features internal passages that allow fluid to bypass the piston, providing a smooth ride while effectively managing damping forces during extreme conditions. The shock is a direct replacement option that enhances ride quality and maximizes wheel travel, making it suitable for various applications.
Constructed with an aluminum body, this shock dissipates heat more efficiently than traditional steel options, ensuring consistent performance under demanding conditions. The external reservoir system further aids in heat dissipation, contributing to the longevity and reliability of the shock. With a serviceable and tunable design, users can maintain optimal performance over time.
Incorporating 35 years of race-winning technology, the FOX shock is specifically tuned for vehicle applications, ensuring compatibility and performance. The nitrile bushings enhance articulation, while the redundant sealing system ensures durability and long-lasting performance. This shock is designed for those seeking a reliable and high-performing suspension solution.
Features
- Packed With 35 Years Of Race Winning Technology
- Performance Tuned For Vehicle Specific Application
- Aluminum Body Dissipates Heat Faster Than Steel. Black Anodized CNC Machined Aluminum Components
- External Reservoir System Dissipates Heat Fast
- 100 Percent Serviceable And Tunable For Longer Lifespan
- Nitrile Bushings Allow For Increased Articulation
- Redundant Sealing System And Long Lasting Performance
Specifications
- Manufacturer: Fox Shocks
- Manufacturer Part Number: 985-24-054
- Type: Hydraulic/ Nitrogen Gas Charged
- With Coil Spring: No
- Extended Length (IN): 30.45 Inch
- Compressed Length (IN): 18.35 Inch
- Upper Mounting Style: Eyelet
- Lower Mounting Style: Eyelet
- Adjustable Valving: No
- Quantity: Single
- Universality: Vehicle Specific
- Internal Design: Monotube
- Body Color: Silver
- Rod Diameter (IN): 5/8 Inch
- Valving Type: Application Specific Valving
- Rod Material: Steel
- Body Material: Aluminum
- With Reservoir: Yes
- Includes Dust Shield: No
- Includes Hardware: Yes
- Includes Boot: No
- Estimated Install Time (Hours): 0.5
Compatibility / Fit
- 2008-2008 Dodge Ram 1500
Technical Documents
Shipping & Returns
- This product ships within the continental USA only.
- This product typically ships within 1 to 3 business days.
- Returns are accepted within 30 days for items in like-new condition. For complete details, please see our return policy.
