Enhance on and off-road performance with advanced damping technology.
The Fox 2.5 Performance Series HTO shock is engineered for improved vehicle handling and comfort, featuring a robust hydraulic and nitrogen gas charged design. This shock utilizes position-sensitive technology and vehicle-specific valving to optimize performance across various terrains. The 2-1/2 inch impact extruded aluminum body is treated with type II anodized plating, ensuring durability and resistance to corrosion while effectively dissipating heat during operation.
Incorporating an internal floating piston (IFP), this shock separates the shock oil from high-pressure nitrogen, enhancing damping capabilities. The Hydraulic Top Out (HTO) technology provides controlled rebound damping, reducing harsh impacts and improving ride quality, especially beneficial for vehicles with heavier tires or those lifted beyond OEM specifications. The shock is designed for easy bolt-on installation, making it a practical choice for those seeking to upgrade their suspension system.
With features such as high-flow velocity-sensitive damping and a 5/8 inch hard chrome shaft, the Fox 2.5 Performance Series HTO shock delivers reliable performance and comfort. This single shock unit is specifically designed for vehicle compatibility, ensuring optimal fit and function.
Features
- 2-1/2 Inch Impact Extruded 6061-T6 Aluminum Shock Body
- Type II Clear-Anodized Body Plating
- High-Flow Velocity-Sensitive Damping
- Features 5/8 Inch Hard Chrome Shaft
- Features Internal Floating Piston Hydraulic Top Out Piston
Specifications
- Manufacturer: Fox Shocks
- Manufacturer Part Number: 987-24-000
- Type: Hydraulic/ Nitrogen Gas Charged
- With Coil Spring: No
- Extended Length (IN): 22.1 Inch
- Compressed Length (IN): 14.8 Inch
- Upper Mounting Style: Stud
- Lower Mounting Style: Eyelet
- Adjustable Valving: No
- Quantity: Single
- Universality: Vehicle Specific
- Body Color: Silver
- Rod Diameter (IN): 5/8 Inch
- Valving Type: Non Adjustable Valving
- Body Material: Aluminum
- With Reservoir: No
- Includes Dust Shield: No
- Includes Hardware: Yes
- Includes Boot: No
- Estimated Install Time (Hours): 0.5
Compatibility / Fit
- 2017-2026 Ford F-250 Super Duty
- 2017-2026 Ford F-350 Super Duty
