Engineered for strength and safety in winching applications.
The Factor 55 ProLink XXL is a robust winch shackle mount designed to enhance the safety and efficiency of winching operations. Constructed from high-quality 6000 series billet aluminum, this mount replaces traditional winch hooks with a more secure screw pin shackle or D-ring. With a working load limit of 24,000 pounds and an ultimate failure rating exceeding 63,000 pounds, the ProLink XXL is engineered to handle demanding tasks, making it suitable for both military and civilian applications.
This mount is compatible with 1/2 inch steel cables and synthetic winch ropes, as well as 3/4 inch and 7/8 inch shackles. The inclusion of a 3/4 inch diameter grade 5 titanium double shear pin ensures durability and reliability under heavy loads. Additionally, the base is protected by a barbed high durometer EPDM rubber guard, which enhances its longevity and performance in rugged environments.
Factor 55 employs advanced design techniques, utilizing 3D CAD software and Finite Element Analysis (FEA) to optimize the ProLink XXL for maximum strength and functionality. Each product undergoes rigorous testing to ensure it meets high standards of quality and performance. Available in multiple anodized colors, the ProLink XXL combines functionality with aesthetic appeal, making it a valuable addition to any winching setup.
Features
- Made From Billet Aluminum Construction These Come With An Upgraded Titanium Shear Pin
- Base Is Protected By The Barbed High Durometer EPDM Rubber Guard
- All Factor 55 Products Are Designed In House Using The Latest 3D CAD Software And Optimized Using Cosmos FEA (Finite Element Analysis)
- Also Perform A Destructive Test On Each Design With The Assistance Of A Test Facility Equipped With Test Measurement And Data Recording Equipment
- Factor 55 Wants To Make Sure We Are Producing The Highest Quality, Best Value Products For Our Customers
Specifications
- Manufacturer: Factor 55
- Manufacturer Part Number: 00210-05
- Shackle Type: 3/4 And 7/8 Inch Shackles/ D-Rings
- Cable Type: 1/2 Inch Steel Cable/ Synthetic Winch Rope
- Load Capacity (LB): 24000 Pound
- Shear Pin Size (IN): 3/4 Inch
- Finish: Anodized
- Color: Silver
- Material: Aluminum
- With Guard: Yes
Technical Documents
Product Videos
Shipping & Returns
- This product ships within the continental USA only.
- This product typically ships within 1 to 3 business days.
- Returns are accepted within 30 days for items in like-new condition. For complete details, please see our return policy.
