Enhance offroad performance and maintain smooth highway ride.
The Fabtech Motorsports lift kit is engineered for the GMC Sierra and Chevy Silverado 3500HD, providing a robust 6 inch lift for both front and rear. This system is designed to enhance offroad capabilities while ensuring a smooth ride on highways. The innovative RTS design retains the factory location of the torsion bars, allowing for superior ground clearance without compromising the vehicle's load carrying capacity, making it suitable for towing and hauling tasks.
Constructed with heavy-duty 1/4 inch thick steel, the bracketry of this lift kit ensures additional strength and rigidity to the suspension. The arched lower control arm crossmembers are designed to provide ground clearance and include a skid plate to protect the front differential from offroad obstacles. The installation process is streamlined, requiring only four holes to be drilled and no cutting of the front differential housing, which facilitates a quicker setup.
This lift kit not only improves the vehicle's offroad performance but also maintains a clean appearance. The inclusion of front and rear bump stop brackets prevents over cycling of the suspension, ensuring durability and reliability. With high-quality components, this lift kit is built to provide years of trouble-free service while enhancing the overall driving experience.
Features
- Heavy-Duty Bracketry Constructed Of 1/4 Inch Thick Steel For Additional Suspension Strength
- Torsion Bars Remain In The Factory Frame Location For Maximum Ground Clearance
- RTS Torsion Bar Brackets Index The Bars At Factory Setting For A Smooth Ride
- Front And Rear Bump Stop Brackets Eliminate Over Cycling Of Suspension
Specifications
- Manufacturer: Fabtech Motorsports
- Manufacturer Part Number: K1161
- Front Lift Amount (IN): 6 Inch
- Rear Lift Amount (IN): 6 Inch
- Maximum Tire Size: 37 x 12.50
- Front Lift Type: Steering Knuckles
- Rear Lift Type: Blocks And U-Bolts
- Shock Type: Hydraulic
- Wheel Backspacing (IN): 5.75
- Minimum Wheel Diameter: 18
- Wheel Offset (MM): 19.05
- Shocks: With Shocks In Kit
- Color: Black Components/ Black Shock Absorbers
Compatibility / Fit
- 2020-2023 Chevrolet Silverado 3500 HD
- 2020-2023 GMC Sierra 3500 HD
