High-output LED fog lights designed for Jeep JL Wrangler installation.
The Diode Dynamics Stage Series Sport Fog Light is engineered to enhance visibility and safety during adverse weather conditions. Featuring advanced TIR optics, these 3-inch round LED bulbs deliver a powerful 1930 raw lumens output while maintaining SAE-compliant road-legal performance. The durable black aluminum cast housing and clear polycarbonate lens ensure longevity and resilience against the elements, making them suitable for off-road and on-road use alike.
Designed specifically for the Jeep JL Wrangler, this set of two fog lights includes all necessary mounting brackets and adapters for a straightforward installation process. The plug-and-play design eliminates the need for modifications, allowing for a quick replacement of factory fog lamps. The innovative optics reduce glare and improve light efficiency, directing all output precisely where it is needed without losing intensity.
With a wattage of 14.5 watts and a low amp draw of 1.1 amps at 12.8 volts, these LED fog lights are energy-efficient while providing superior illumination. The yellow Luxeon Z ES LED bulbs are optimized for fog beam patterns, ensuring maximum functionality in challenging driving conditions. The Stage Series Sport Fog Light is a reliable choice for those seeking enhanced performance and visibility.
Features
- Advanced TIR Optics Provide High Efficiency And Focus
- SAE-Compliant Road-Legal Output
- Features Round Bezel, For Factory-Style Appearance
- Plug And Play, No Modification Needed
- Durable Powdercoated Aluminum Die-Cast
- Direct Replacement For Jeep JL Wrangler Fog Lamps
- Engineered And Assembled In USA
- Traditional Optics Like Reflectors Or Simple Lenses Lose Light Internally And To Glare, So Not All Of The Light Shines On Target
- All Stage Series Beam Pattern Options Were Designed With Optical Simulation Modeling, To Shape The Output In A Highly-Functional Beam Pattern
Specifications
- Manufacturer: Diode Dynamics
- Manufacturer Part Number: DD7053
- Shape: Round
- Beam Type: Fog Beam
- Diameter: 3 Inch
- Height/ Width: Not Applicable
- Bulb Type: LED
- Light Color: Amber
- Quantity: Set Of 2
- Universality: Vehicle Specific
- Depth: 1-5/8 Inch
- Wattage: 14.5 Watt
- Voltage Rating: 9 To 16 Volt
- Mounting Style: Bracket Mount
- Lumens: 1930 Lumens
- Bulb Specifications: Yellow Luxeon Z ES LED Bulbs
- Lens Material: Polycarbonate
- Housing Color: Black
- Housing Material: Aluminum
- Includes: With Two Plastic Type M Base Mounting Brackets/ Two 9006 DT Adapters/ Two 5202 DT Adapters/ Hardware
- Estimated Install Time (Hours): 1.5
Compatibility / Fit
- 2020-2025 Jeep Gladiator JT
- 2018-2018 Jeep Wrangler JK
- 2018-2025 Jeep Wrangler JL
