CSF Radiator With Transmission Cooler (MPN: 3967)

High performance aluminum core radiator designed for optimal cooling efficiency.

The CSF Radiator is engineered for high performance and reliability, featuring a single row downflow design with an aluminum core and durable plastic tanks. With core dimensions of 14-3/4 inches in length, 29-1/16 inches in height, and 5/8 inch in depth, this radiator is designed to fit seamlessly into a variety of vehicle models. The inlet hose is located at the top left, while the outlet hose is positioned at the bottom center, ensuring efficient coolant flow.

Constructed with OEM specified materials, the radiator's tanks are made from virgin grade engineered plastic resins that are glass filled for enhanced strength and durability. The design includes high performance multi-louvered fins and welded type tubes, which contribute to superior cooling performance. Each unit undergoes rigorous testing, including a 100 percent leak test at 150 percent of operating pressure, ensuring reliability under extreme conditions.

CSF has over 50 years of experience in manufacturing radiators, with a commitment to high performance standards and quality assurance. This radiator is equipped with a built-in transmission cooler featuring a special turbulator for improved fluid dynamics, making it suitable for a wide range of applications. The product is packaged to withstand industry best standards, ensuring safe delivery and installation.

Features

• OEM Specified Plastic Tank-Aluminum Core Construction
• Tanks Are Made From Virgin Grade Engineered Plastic Resins, Which Are Glass Filled For Added Strength And Durability
• Gaskets Are Made From Special Grade EPDM Rubber To Withstand Extreme Temperatures Of Up To Minus 120 Degrees Fahrenheit
• Tubes: Welded Type Or Latest Generation B-Tube Design
• Fins: High Performance Multi-Louvered Design And OEM Specification
• 100 Percent Leak Tested Before Leaving Factory At 150 Percent Of Operating Pressure
• Industry Best Packaging: 10 Foot Drop Test Standard
• Drop-In Fit And High Performance Transmission Cooler With Special Built-In Turbulator, When Applicable
• All Components Are Installed, Torqued, And Tested On Radiator During Assembly

Specifications

• Manufacturer: CSF
• Manufacturer Part Number: 3967
• Flow Direction: Downflow
• Core Rows: Single
• Core Material: Aluminum
• Inlet Hose Location: Top Left
• Inlet Size (IN): 1-5/16 Inch
• Outlet Hose Location: Bottom Center
• Finish: Natural
• Color: Black/ Silver
• Core Length (IN): 14-3/4 Inch
• Core Height (IN): 29-1/16 Inch
• Core Depth (IN): 5/8 Inch
• Tank Material: Plastic
• With Radiator Cap: No
• With Transmission Cooler: Yes
• With Engine Oil Cooler: No
• Includes Fittings: No
• Includes Mounting Hardware: No

Compatibility / Fit

• 2014-2018 Mazda 3
