CSF Radiator (MPN: 3516)

High performance aluminum radiator with advanced cooling technology.

The CSF Radiator features a robust aluminum core with plastic tanks, designed for optimal cooling efficiency. With core dimensions of 23-1/2 inches in length, 18-11/16 inches in height, and 1-5/8 inches in depth, this dual-row radiator is engineered to meet high performance standards. It includes a high performance transmission cooler and an engine oil cooler, ensuring effective temperature regulation under various operating conditions.

Constructed with OEM specified plastic tank-aluminum core technology, the tanks are made from virgin grade engineered plastic resins that are glass filled for enhanced strength and durability. The radiator is equipped with special grade EPDM rubber gaskets that can withstand extreme temperatures, making it suitable for demanding environments. Each unit is 100 percent leak tested at 150 percent of operating pressure before leaving the factory, ensuring reliability and performance.

The innovative design includes welded type or the latest generation B-tube design for improved fluid flow, along with a high performance multi-louvered fin design that maximizes heat dissipation. This radiator is a testament to CSF's commitment to quality, having been sold worldwide for over 50 years with more than 30 million units sold.

Features

• OEM Specified Plastic Tank-Aluminum Core Construction
• Tanks Are Made From Virgin Grade Engineered Plastic Resins, Which Are "Glass Filled" For Added Strength And Durability
• Gaskets Are Made From Special Grade "EPDM" Rubber To Withstand Extreme Temperatures Of Up To -120 Degrees Fahrenheit
• Tubes: Welded Type Or Latest Generation "B-Tube" Design
• Fins: High Performance "Multi-Louvered Design" - OEM Spec
• 100 Percent Leak Tested Before Leaving Factory At 150 Percent Of Operating Pressure
• High Performance Transmission Cooler With Special Built-In Turburlator, When Applicable
• All Components Are Installed, Torqued, And Tested On Radiator During Assembly

Specifications

• Manufacturer: CSF
• Manufacturer Part Number: 3516
• Flow Direction: Crossflow
• Overall Length (IN): OEM
• Overall Height (IN): OEM
• Overall Depth (IN): OEM
• Core Rows: Dual
• Core Material: Aluminum
• Inlet Hose Location: Top Left
• Inlet Size (IN): 1-3/4 Inch
• Outlet Hose Location: Bottom Right
• Outlet Size (IN): 1-3/4 Inch
• Finish: Natural
• Color: Black/ Silver
• Core Length (IN): 23-1/2 Inch
• Core Height (IN): 18-11/16 Inch
• Core Depth (IN): 1-5/8 Inch
• Tank Material: Plastic
• With Radiator Cap: No
• With Transmission Cooler: Yes
• With Engine Oil Cooler: Yes
• Includes Fittings: No
• Includes Mounting Hardware: No

Compatibility / Fit

• 2000-2004 Dodge Dakota
• 2000-2003 Dodge Durango
