Efficient 6 Position Circuit Breaker Block for Reliable Power Management
The Blue Sea Circuit Breaker Block is designed for efficient power management in various applications. This 6 position independent source block allows for a maximum operating current of 32 amps per circuit and 40 amps for jumped circuit groups, making it suitable for demanding electrical systems. With a maximum operating voltage of 32 volts DC, it operates effectively within a temperature range of -10 to 60 degrees Celsius.
Featuring a compact design, the snap-in mount allows for easy installation, comparable to that of a fuse. The quick connect clips facilitate a straightforward setup, while the tin-plated copper busses and screw terminals ensure reliable connectivity. The clear insulating cover meets ABYC and USCG insulation requirements, providing safety and compliance in marine environments.
Additional features include easy access for wiring in two directions and the option to install waterproof boots or dress nuts over the cover. This circuit breaker block is engineered for durability and ease of use, making it a practical choice for both professionals and DIY enthusiasts.
Features
- Quick Connect Clips Allow Circuit Breakers To Snap Easily Into Place
- Tin-Plated Copper Busses And Screw Terminals
- Clear Insulating Cover With Square Format Label Recesses, Satisfies ABYC/USCG Insulation Requirements
- Easy To Open Clip On Cover
- Breakouts Allow Wire Access In Two Directions
- Accepts Ring Terminals
- Optional Push Button Waterproof Boots Or Dress Nuts Can Be Installed Over Cover
- Easy To Install
Specifications
- Manufacturer: Blue Sea
- Manufacturer Part Number: 5050-BSS
- Number Of Circuits: 6 Position Independent Source Without Ground Base
- Ampere Rating: 32 Amp Per Circuit/ 40 Amp Per Jumped
- Voltage Rating: 32 Volt DC
- Operating Temperature: -10 Degree Celsius To 60 Degree Celsius
- Mounting Type: Snap-In
- With Insulating Cover: Yes
