Blue Sea Circuit Breaker (MPN: 7310-BSS)

Reliable circuit protection for marine and electrical applications.

The Blue Sea Circuit Breaker is designed for efficient circuit protection in various applications, including marine environments. With a 5 Amp rating and dual voltage capability of 65 Volts DC and 277 Volts AC, this double pole magnetic hydraulic type breaker ensures reliable operation. Its compact design allows for high density circuit protection configurations, making it suitable for installations where space is limited.

Featuring a push-to-reset operation, this circuit breaker is designed to trip free, ensuring it cannot be held in the 'ON' position during fault current conditions. This safety feature is crucial for maintaining operational integrity in critical systems. Additionally, the ignition protected design makes it safe for installation aboard gasoline powered boats, enhancing its versatility in marine applications.

The circuit breaker includes a quick connect terminal style, compatible with Blue Sea Systems WeatherDeck Waterproof Circuit Breaker Panels and other distribution panels. An optional push button waterproof boot is available to protect the circuit breaker in wet environments, preventing discoloration and cracking. This product is an essential component for reliable electrical management in both marine and land-based systems.

Features

• Compact Design Enables High Density Circuit Protection Configurations
• Push-To-Reset Operation
• Trip Free Design Cannot Be Held “ON” During Fault Current Condition
• Ignition Protected - Safe For Installation Aboard Gasoline Powered Boats

Specifications

• Manufacturer: Blue Sea
• Manufacturer Part Number: 7310-BSS
• Ampere Rating: 5 Amp
• Voltage Rating: 65/ 277 Volt
• Reset Type: Manual
• Terminal Connection: Screw
• Type: Double Pole Magnetic Hydraulic
• Number of Poles: 2
• Quantity: Single
• Estimated Install Time (Hours): 0.25
