Blue Sea Circuit Breaker (MPN: 7187-BSS)

Reliable circuit protection for marine and vehicle electrical systems.

The Blue Sea Circuit Breaker is designed to provide medium duty circuit protection for loads ranging from 25 to 150 Amps. This breaker is suitable for both AC and DC electrical systems in marine and vehicle applications, ensuring safe operation under various conditions. It features a manual and switchable reset type, allowing for easy reactivation after a trip. The thermal bi-metal blade design ensures reliable performance across a wide operating temperature range of 40 degrees Celsius to +85 degrees Celsius.

This circuit breaker is a drop-in replacement for 185-Series circuit breakers, making it convenient for upgrades or replacements. The visible reset lever indicates the open condition, enhancing user awareness and safety. Additionally, it is ignition protected, meeting the SAE J1171 external ignition protection requirements, making it safe for installation aboard gasoline-powered boats. With its weather-resistant construction, this circuit breaker combines switching and circuit protection functions into a single unit, providing a compact and efficient solution for electrical systems.

Features

• Drop In Replacement For 185-Series Circuit Breakers
• Visible Reset Lever Shows Open Condition
• Ignition Protected - Safe For Installation Aboard Gasoline Powered Boats
• Meets SAE J1171 External Ignition Protection Requirements
• Weather Resistant
• Combines Switching And Circuit Breaker Function Into One Unit
• Trip Free

Specifications

• Manufacturer: Blue Sea
• Manufacturer Part Number: 7187-BSS
• Ampere Rating: 100 Amp
• Voltage Rating: 48 Volt
• Reset Type: Manual And Switchable
• Terminal Connection: Stud
• Type: Thermal
• Quantity: Single
• Estimated Install Time (Hours): 0.25
