B&B Molders Fresh Water Inlet (MPN: 94222)

Durable and Certified Fresh Water Inlet for RV Systems

The B&B Molders Fresh Water Inlet is designed for use in RV fresh water systems, providing a reliable gravity water fill option. This inlet accommodates either 1-1/4 inch or 1-3/8 inch water fill hoses, ensuring compatibility with various setups. Constructed from UV and impact resistant plastic, it features a non-yellowing polar white finish that maintains its appearance over time. The inlet includes a built-in plastic check valve with a 1/2 inch male pipe thread, enhancing functionality and preventing backflow.

With dimensions of 5-5/16 inches in height and 7-9/16 inches in width, the inlet is designed for recessed mounting with a cutout size of 6 inches in width and 3-3/4 inches in height. It also includes a 3/8 inch tank vent connection, making it a versatile choice for RV applications. The product is factory tested for zero leakage and is certified by IAPMO, NSF, and CSA, ensuring compliance with industry standards. Made in the USA, this inlet is a reliable choice for both original factory parts and direct OEM replacements.

Features

• UV Stable And Colorfast
• Impact And Road Salt Resistant
• Non-Yellowing White
• Original Factory Parts Or Direct OEM Replacement
• Plastic Check Valve With 1/2 Inch Male Pipe Thread
• Spout Accepts Either 1-1/4 Inch Or 1-3/8 Inch Water Fill Hose; Features 3/8 Inch Tank Vent Connection
• Factory Tested For Zero Leakage
• IAPMO, NSF And CSA Certified
• Made In USA

Specifications

• Manufacturer: B&B Molders
• Manufacturer Part Number: 94222
• Inlet Connection: City Water Female Threads and Gravity Feed
• Mounting Type: Recessed Mount
• Recess Depth: 2-1/2 Inch
• Outlet Connection: 1/2 Inch Male Threads
• Tank Vent: 3/8 Inch Tank Vent
• Cutout Size (IN): 6 Inch Width X 3-3/4 Inch Height
• Diameter (IN): Not Applicable
• Width (IN) And Height (IN): 7-9/16 Inch Width X 5-5/16 Inch Height
• Color: Polar White
• Material: Plastic
• With Dust Cover: Yes
• With Built-In Check Valve: Yes
