Compact and accurate gauge solution for performance vehicles
The AutoMeter Quad Gauge System is designed to provide essential readings in a compact format, making it suitable for vehicles with limited dashboard space. This system includes four key gauges: fuel level, oil pressure, speedometer, and tachometer, all housed in a sleek 5-inch design. Each gauge features individual air core meter movements, ensuring precise and reliable readings for critical engine parameters. The voltmeter operates within a range of 8 to 18 volts, while the fuel level gauge accurately measures from 240 ohms empty to 33 ohms full.
The speedometer offers a full sweep from 0 to 120 MPH and includes a simple push-button calibration feature, allowing for easy adjustments to accommodate changes in gear ratios or tire sizes. Additionally, the tachometer supports a range of 0 to 8000 RPM and is compatible with various ignition signals, making it versatile for different engine configurations. The gauges are illuminated with yellow LED lighting, enhancing visibility in low-light conditions.
Constructed with an ivory and black face, chrome bezel, and black needle, the AutoMeter Quad Gauge System combines functionality with a clean aesthetic. This system is compatible with most 12V high-performance racing ignitions and includes all necessary gauge senders, ensuring a straightforward installation process. With its race-proven design, this gauge system meets the demands of both street and race applications.
Features
- Traditional Incandescent Lighting Illuminates Around The Perimeter Of The Dial
- Race Proven Air-Core Electric Instruments Provide Quick And Accurate Readings While Keeping Hazardous Fluids Outside Of The Vehicle
- Speedometer Has A Simple Push Button, 2 Mile Drive Calibration
- No Dip Switches And Can Be Reprogramed At Any Time To Accommodate Changes In Gear Ratio Or Wheel And Tire Combination
- Speedometer Features Lit LCD Odometer - Capable Of Registering One-Million Miles With Two Resettable Trip Odometers
- Speedometer Is Compatible With Most Two Wire Sine Wave And Three Wire Hall Effect Vehicle Speed Sensors
- 4 In 1 Gauge Design Saves Valuable Real Estate On Your Dash While Allowing You To Monitor Critical Parameters
- Tachometer Is Compatible With 0.5 To 6 Pulse Ignition Signals (1 To 12 Cylinder Engines) With Points, Electronic, And Most 12 Volt High-Performance Racing Ignitions
- 12 And 16 Volt Compatible, Compatible With Nearly Every Street Car Or Race Car Electrical System
Specifications
- Manufacturer: AutoMeter
- Manufacturer Part Number: 2004
- Size (IN): 5 Inch
- Type: Electrical
- Fuel Level Gauge Range (OHM): 240 Ohms Empty/ 33 Ohms Full
- Oil Pressure Gauge Range (PSI): 0 To 100 Pounds Per Square Inch
- Speedometer Range (MPH): 0 To 120 Miles Per Hour
- Tachometer Range (RPM): 0 To 8000 RPM
- Voltmeter Range (Volt): 8 To 18 Volt
- Water Temperature Gauge Range (Deg F): 100 To 250 Degree Fahrenheit
- Display: Analog
- Sweep: Full Sweep
- Face Color: Ivory And Black
- Needle Color: Black
- Bezel Color: Silver
- Number Color: Black
- Mounting Type: Dash Mount
- Lighting: Yellow LED
- Includes Warning Indicator: No
- Warning Indicator Type: Not Applicable
- Includes Peak Memory: No
- Liquid-Filled: No
- Includes Sending Unit: Yes
- Includes Wiring Harness: No
- Includes Fittings: Yes
- Includes Mounting Bracket: Yes
