AutoMeter Quad Gauge System (MPN: 1620)

AutoMeter Quad Gauge System (MPN: 1620)

  • Sale
  • $1,125.18
Accepted Credit Cards

Compact design with essential readings for performance monitoring.

The AutoMeter Quad Gauge System is designed to provide critical engine parameters in a compact format, making it suitable for limited dashboard space. This system includes four essential gauges: fuel level, oil pressure, speedometer, and tachometer, all housed in a 3-3/8 inch analog display. Each gauge features individual air core meter movements, ensuring accuracy and durability for demanding applications. The voltmeter operates within a range of 8-18 volts, while the fuel level gauge measures from 240 ohms empty to 33 ohms full, providing reliable readings for various engine types.

The speedometer offers a full sweep from 0 to 120 MPH and includes a simple push button for two-mile drive calibration, allowing for easy adjustments to accommodate changes in gear ratios or tire sizes. The tachometer is compatible with a wide range of ignition signals, making it versatile for use with 0.5 to 6 pulse ignition systems. Additionally, the traditional incandescent lighting illuminates the perimeter of the dial, enhancing visibility in low-light conditions.

This gauge system is compatible with most 12V high-performance racing ignitions and is designed to operate on 4, 6, or 8 cylinder engines. The inclusion of all necessary gauge senders ensures a straightforward installation process. The AutoMeter Quad Gauge System combines functionality and style, making it an essential tool for monitoring engine performance.

Features

  • Traditional Incandescent Lighting Illuminates Around The Perimeter Of The Dial
  • Race Proven Air-Core Electric Instruments Provide Quick And Accurate Readings While Keeping Hazardous Fluids Outside Of The Vehicle
  • Speedometer Has A Simple Push Button, 2 Mile Drive Calibration
  • No Dip Switches And Can Be Reprogramed At Any Time To Accommodate Changes In Gear Ratio Or Wheel And Tire Combination
  • Speedometer Features Lit LCD Odometer - Capable Of Registering One-Million Miles With Two Resettable Trip Odometers
  • 4 In 1 Gauge Design Saves Valuable Real Estate On Your Dash While Allowing You To Monitor Critical Parameters
  • Tachometer Is Compatible With 0.5 To 6 Pulse Ignition Signals (1 To 12 Cylinder Engines) With Points, Electronic, And Most 12 Volt High-Performance Racing Ignitions
  • 12 And 16 Volt Compatible, Compatible With Nearly Every Street Car Or Race Car Electrical System

Specifications

  • Manufacturer: AutoMeter
  • Manufacturer Part Number: 1620
  • Size (IN): 3-3/8 Inch
  • Type: Electrical
  • Fuel Level Gauge Range (OHM): 240 Ohms Empty/ 33 Ohms Full
  • Oil Pressure Gauge Range (PSI): 0 To 100 Pounds Per Square Inch
  • Speedometer Range (MPH): 0 To 120 Miles Per Hour
  • Tachometer Range (RPM): 0 To 8000 RPM
  • Voltmeter Range (Volt): 8 To 18 Volt
  • Water Temperature Gauge Range (Deg F): 100 To 250 Degree Fahrenheit
  • Display: Analog
  • Sweep: Full Sweep
  • Face Color: White
  • Needle Color: Black
  • Bezel Color: Silver
  • Number Color: Black
  • Mounting Type: In-Dash
  • Lighting: Incandescent
  • Includes Warning Indicator: No
  • Warning Indicator Type: Not Applicable
  • Includes Peak Memory: No
  • Liquid-Filled: No
  • Includes Sending Unit: Yes
  • Includes Wiring Harness: No
  • Includes Fittings: No
