Compact and accurate multi-gauge solution for performance vehicles.

The AutoMeter Quad Gauge System is designed to optimize dashboard space while delivering precise readings for critical vehicle parameters. This system includes four essential gauges: fuel level, oil pressure, speedometer, and tachometer, all housed in a sleek 3-3/8 inch design. Each gauge features traditional incandescent lighting that illuminates the perimeter of the dial, ensuring visibility in various lighting conditions.

The fuel level gauge operates within a resistance range of 240 ohms when empty to 33 ohms when full, while the oil pressure gauge measures from 0 to 100 PSI. The speedometer provides a full sweep from 0 to 120 MPH and includes a simple push-button calibration feature, allowing for easy adjustments based on gear ratio or tire size changes. The tachometer supports a range of 0 to 8000 RPM and is compatible with various ignition signals, making it suitable for a wide range of engine types.

This gauge system is engineered for durability and accuracy, utilizing race-proven air-core electric instruments that keep hazardous fluids outside the vehicle. The voltmeter reads from 8 to 18 volts, compatible with most 12V high-performance racing ignitions, while the water temperature gauge monitors temperatures from 100 to 250 degrees Fahrenheit. The AutoMeter Quad Gauge System is an essential tool for any performance enthusiast looking to maintain optimal vehicle performance.

Features

  • Traditional Incandescent Lighting Illuminates Around The Perimeter Of The Dial
  • Race Proven Air-Core Electric Instruments Provide Quick And Accurate Readings While Keeping Hazardous Fluids Outside Of The Vehicle
  • Speedometer Has A Simple Push Button, 2 Mile Drive Calibration
  • No Dip Switches And Can Be Reprogramed At Any Time To Accommodate Changes In Gear Ratio Or Wheel And Tire Combination
  • Speedometer Features Lit LCD Odometer - Capable Of Registering One-Million Miles With Two Resettable Trip Odometers
  • 4 In 1 Gauge Design Saves Valuable Real Estate On Your Dash While Allowing You To Monitor Critical Parameters
  • Tachometer Is Compatible With 0.5 To 6 Pulse Ignition Signals (1 To 12 Cylinder Engines) With Points, Electronic, And Most 12 Volt High-Performance Racing Ignitions
  • 12 And 16 Volt Compatible, Compatible With Nearly Every Street Car Or Race Car Electrical System

Specifications

  • Manufacturer: AutoMeter
  • Manufacturer Part Number: 1409
  • Size (IN): 3-3/8 Inch
  • Type: Electrical
  • Fuel Level Gauge Range (OHM): 240 Ohms Empty/ 33 Ohms Full
  • Oil Pressure Gauge Range (PSI): 0 To 100 Pounds Per Square Inch
  • Speedometer Range (MPH): 0 To 120 Miles Per Hour
  • Tachometer Range (RPM): 0 To 8000 RPM
  • Voltmeter Range (Volt): 8 To 18 Volt
  • Water Temperature Gauge Range (Deg F): 100 To 250 Degree Fahrenheit
  • Display: Analog
  • Sweep: Full Sweep
  • Face Color: Black
  • Needle Color: Orange
  • Bezel Color: Silver
  • Number Color: White
  • Mounting Type: In-Dash
  • Lighting: Incandescent
  • Includes Warning Indicator: No
  • Warning Indicator Type: Not Applicable
  • Includes Peak Memory: No
  • Liquid-Filled: No
  • Includes Sending Unit: Yes
  • Includes Wiring Harness: No
  • Includes Fittings: No
