Compact and accurate gauge solution for performance vehicles

The AutoMeter Quad Gauge System is designed to provide essential readings in a compact format, making it suitable for vehicles with limited dashboard space. This system includes four electric analog gauges: fuel level, oil pressure, speedometer, and tachometer, all housed in a 5-inch design. Each gauge features modern LED through-the-dial lighting for enhanced visibility during nighttime use, ensuring that critical information is always accessible.

The fuel level gauge operates within a resistance range of 240 ohms empty to 33 ohms full, while the oil pressure gauge measures from 0 to 100 PSI. The speedometer offers a full sweep from 0 to 120 MPH and includes a simple push-button calibration feature, allowing for easy adjustments to accommodate changes in gear ratios or tire sizes. The tachometer reads from 0 to 8000 RPM and is compatible with various ignition signals, making it versatile for different engine types.

Constructed with durability in mind, the AutoMeter Quad Gauge System utilizes race-proven air-core electric instruments that provide quick and accurate readings while keeping hazardous fluids outside the vehicle. This system is compatible with most 12V high-performance racing ignitions and is designed to meet the demands of both street and race applications.

Features

  • Modern LED Through-The-Dial Lighting Provides Clear Visibility During Nighttime Use
  • Race Proven Air-Core Electric Instruments Provide Quick And Accurate Readings While Keeping Hazardous Fluids Outside Of The Vehicle
  • Speedomete Has Simple Push Button, 2 Mile Drive Calibration
  • No Dip Switches And Can Be Reprogramed At Any Time To Accommodate Changes In Gear Ratio Or Wheel And Tire Combination
  • Speedometer Features Lit LCD Odometer - Capable Of Registering One-Million Miles With Two Resettable Trip Odometers
  • Speedometer Is Compatible With Most Two Wire Sine Wave And Three Wire Hall Effect Vehicle Speed Sensors
  • 12 And 16 Volt Compatible, Compatible With Nearly Every Street Car Or Race Car Electrical System
  • Tachometer Is Compatible With 0.5 To 6 Pulse Ignition Signals (1 To 12 Cylinder Engines) With Points, Electronic, And Most 12 Volt High-Performance Racing Ignitions
  • 4 In 1 Gauge Design Saves Valuable Real Estate On Your Dash While Allowing You To Monitor Critical Parameters

Specifications

  • Manufacturer: AutoMeter
  • Manufacturer Part Number: 1203
  • Size (IN): 5 Inch
  • Type: Electrical
  • Fuel Level Gauge Range (OHM): 240 Ohms Empty/ 33 Ohms Full
  • Oil Pressure Gauge Range (PSI): 0 To 100 Pounds Per Square Inch
  • Speedometer Range (MPH): 0 To 120 Miles Per Hour
  • Tachometer Range (RPM): 0 To 8000 RPM
  • Voltmeter Range (Volt): 8 To 18 Volt
  • Water Temperature Gauge Range (Deg F): 100 To 250 Degree Fahrenheit
  • Display: Analog
  • Sweep: Full Sweep
  • Face Color: White
  • Needle Color: Black
  • Bezel Color: Silver
  • Number Color: Black
  • Mounting Type: In-Dash
  • Lighting: Illuminated
  • Includes Warning Indicator: No
  • Warning Indicator Type: Not Applicable
  • Includes Peak Memory: No
  • Liquid-Filled: No
  • Includes Sending Unit: Yes
  • Includes Wiring Harness: No
  • Includes Fittings: No
