Compact 4-in-1 gauge solution for precise monitoring.
The AutoMeter Prestige Black Diamond Quad Gauge is designed to provide essential vehicle metrics in a compact format, making it suitable for limited dashboard space. This gauge set includes a fuel level gauge, oil pressure gauge, speedometer, and tachometer, all housed in a sleek black and silver design with a chrome bezel. Each gauge features individual air core meter movements, ensuring accuracy and durability for demanding applications.
The fuel level gauge operates within a resistance range of 240 ohms empty to 33 ohms full, while the oil pressure gauge measures from 0 to 100 PSI. The speedometer offers a full sweep from 0 to 120 MPH and includes a resettable trip odometer, with a simple push-button calibration for easy adjustments. The tachometer ranges from 0 to 8000 RPM and is compatible with various ignition signals, making it versatile for different engine types.
Additional features include a voltmeter that reads from 8 to 18 volts and a water temperature gauge with a range of 100 to 250 degrees Fahrenheit. The gauges are illuminated with traditional incandescent lighting around the perimeter, providing visibility in low-light conditions. This 4-in-1 design not only saves valuable dashboard space but also allows for comprehensive monitoring of critical vehicle parameters.
Features
- Traditional Incandescent Lighting Illuminates Around The Perimeter Of The Dial
- Race Proven Air-Core Electric Instruments Provide Quick And Accurate Readings While Keeping Hazardous Fluids Outside Of The Vehicle
- Speedometer Has A Simple Push Button, 2 Mile Drive Calibration
- No Dip Switches And Can Be Reprogramed At Any Time To Accommodate Changes In Gear Ratio Or Wheel And Tire Combination
- Speedometer Features Lit LCD Odometer - Capable Of Registering One-Million Miles With Two Resettable Trip Odometers
- Speedometer Is Compatible With Most Two Wire Sine Wave And Three Wire Hall Effect Vehicle Speed Sensors
- 4 In 1 Gauge Design Saves Valuable Real Estate On Your Dash While Allowing You To Monitor Critical Parameters
- Tachometer Is Compatible With 0.5 To 6 Pulse Ignition Signals (1 To 12 Cylinder Engines) With Points, Electronic, And Most 12 Volt High-Performance Racing Ignitions
- 12 And 16 Volt Compatible, Compatible With Nearly Every Street Car Or Race Car Electrical System
Specifications
- Manufacturer: AutoMeter
- Manufacturer Part Number: 2005
- Size (IN): 5 Inch
- Type: Electrical
- Fuel Level Gauge Range (OHM): 240 Ohms Empty/ 33 Ohms Full
- Oil Pressure Gauge Range (PSI): 0 To 100 Pounds Per Square Inch
- Speedometer Range (MPH): 0 To 120 Miles Per Hour
- Tachometer Range (RPM): 0 To 8000 RPM
- Voltmeter Range (Volt): 8 To 18 Volt
- Water Temperature Gauge Range (Deg F): 100 To 250 Degree Fahrenheit
- Display: Analog
- Sweep: Full Sweep
- Face Color: Black And Silver
- Needle Color: Silver
- Bezel Color: Silver
- Number Color: Silver
- Mounting Type: Dash Mount
- Lighting: Yellow LED
- Includes Warning Indicator: No
- Warning Indicator Type: Not Applicable
- Includes Peak Memory: No
- Liquid-Filled: No
- Includes Sending Unit: Yes
- Includes Wiring Harness: No
- Includes Fittings: Yes
- Includes Mounting Bracket: Yes
