Compact 4-in-1 gauge solution for precise monitoring of critical engine parameters.
The AutoMeter Designer Black II Quad Gauge is engineered to provide accurate readings for fuel level, oil pressure, speed, and engine RPM in a compact design. This 5-inch analog gauge features a black face with a chrome bezel and illuminated orange needle, ensuring visibility in various lighting conditions. Each gauge operates on 12V systems and is compatible with 4, 6, and 8-cylinder engines, making it versatile for both street and race applications.
The fuel level gauge operates within a resistance range of 240 ohms empty to 33 ohms full, while the oil pressure gauge measures from 0 to 100 PSI. The speedometer offers a full sweep from 0 to 120 MPH and includes a simple push-button calibration feature, accommodating changes in gear ratios or tire sizes. The tachometer reads from 0 to 8000 RPM and is compatible with various ignition signals, ensuring reliable performance across different engine types.
Designed for durability, the AutoMeter Quad Gauge utilizes race-proven air-core electric instruments that keep hazardous fluids outside the vehicle. The modern LED through-the-dial lighting enhances nighttime visibility, making it easier to monitor critical parameters during low-light conditions. This gauge set is an efficient solution for those looking to maximize dashboard space without compromising on functionality.
Features
- Modern LED Through-The-Dial Lighting Provides Clear Visibility During Nighttime Use
- Race Proven Air-Core Electric Instruments Provide Quick And Accurate Readings While Keeping Hazardous Fluids Outside Of The Vehicle
- Speedomete Has Simple Push Button, 2 Mile Drive Calibration
- No Dip Switches And Can Be Reprogramed At Any Time To Accommodate Changes In Gear Ratio Or Wheel And Tire Combination
- Speedometer Features Lit LCD Odometer - Capable Of Registering One-Million Miles With Two Resettable Trip Odometers
- Speedometer Is Compatible With Most Two Wire Sine Wave And Three Wire Hall Effect Vehicle Speed Sensors
- 12 And 16 Volt Compatible, Compatible With Nearly Every Street Car Or Race Car Electrical System
- Tachometer Is Compatible With 0.5 To 6 Pulse Ignition Signals (1 To 12 Cylinder Engines) With Points, Electronic, And Most 12 Volt High-Performance Racing Ignitions
- 4 In 1 Gauge Design Saves Valuable Real Estate On Your Dash While Allowing You To Monitor Critical Parameters
Specifications
- Manufacturer: AutoMeter
- Manufacturer Part Number: 1204
- Size (IN): 5 Inch
- Type: Electrical
- Fuel Level Gauge Range (OHM): 240 Ohms Empty/ 33 Ohms Full
- Oil Pressure Gauge Range (PSI): 0 To 100 Pounds Per Square Inch
- Speedometer Range (MPH): 0 To 120 Miles Per Hour
- Tachometer Range (RPM): 0 To 8000 RPM
- Voltmeter Range (Volt): 8 To 18 Volt
- Water Temperature Gauge Range (Deg F): 100 To 250 Degree Fahrenheit
- Display: Analog
- Sweep: Full Sweep
- Face Color: Black
- Needle Color: Orange
- Bezel Color: Silver
- Number Color: White
- Mounting Type: In-Dash
- Lighting: Illuminated
- Includes Warning Indicator: No
- Warning Indicator Type: Not Applicable
- Includes Peak Memory: No
- Liquid-Filled: No
- Includes Sending Unit: Yes
- Includes Wiring Harness: No
- Includes Fittings: No
