Compact and powerful LED light bar with versatile mounting options.
The ARC Lighting Xtreme LED Light Bar offers a compact design with a length of 5 inches, making it suitable for various applications where traditional light bars may not fit. This light bar features a dual-color LED system, allowing users to switch between bright white for driving and yellow for fog conditions. With a robust output of 2000 lumens and a power draw of 20 watts at 12 volts, it provides significant illumination for both on-road and off-road scenarios.
Constructed with a clear polycarbonate lens and a powder-coated black cast aluminum housing, the Xtreme Light Bar is built to withstand harsh environmental conditions, boasting an IP67K weatherproof rating. The side bracket mount design ensures a secure installation without the need for drilling, and the included mounting hardware simplifies the setup process. This light bar is compliant with SAE J581 standards, ensuring reliable performance and safety.
The modular design of the Xtreme Light Bar allows for stacking and customization, making it adaptable for various lighting needs. Whether for daily driving or off-road adventures, this light bar enhances visibility and safety with its strobe mode feature, ideal for work zones and emergencies. The combination of compact size and high performance makes the ARC Lighting Xtreme LED Light Bar a valuable addition to any vehicle.
Features
- Small Compact LED Light
- Flexible Mounting Options For Versatile Installation
- SAE J581 Compliant
- Weatherproof IP67K Rating Ensures Protection Against Harsh Environmental Conditions
Specifications
- Manufacturer: ARC Lighting
- Manufacturer Part Number: 6403D
- Bulb Type: LED
- Style: Straight
- Length: 5 Inch
- Beam Type: Driving Beam
- Number Of Rows: 1
- Light Color: White/ Yellow
- Housing Color: Black
- Lumens: 2000 Lumens
- Wattage: 20 Watt
- Width: 2-1/2 Inch
- Height: 1-1/2 Inch
- Voltage Rating: 9 To 36 Volt
- Ampere Rating At 12 Volts: 5 Amp
- Bulb Specifications: White/ Yellow LED
- Lens Material: Polycarbonate
- Housing Material: Aluminum
- Mounting Style: Side Bracket Mount
- Connection Type: Pigtail
- Includes: With Two LED Light Bar/ Four Side Mounting Brackets And Hardware
- Estimated Install Time (Hours): 1.5
